JVC MX-DK1US - See Fig.

(No.MB515)1-9
3.1.2 Removing the DVD mechanism assembly
(See Fig.3)
(1) Disconnect the card wires from connector CN300
, CN301
and CN303 of the main board.
(2) Remove the three screws C attaching the DVD mecha-
nism assembly.
Fig.3
C
CN300
CN301
CN302
