MX-K1
3-7
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M2MM
1 GJ4A0430201A1 TRAY 1
2 GJ701222260432 SCREW 4 M2.6 X 4
3 GJ4D01068100A1 MOTOR PULLEY 2 VE75984
4 GJ4D04300501A1 RELAY GEAR-A 1
5 GJ4D04301801A1 PULLEY GEAR 1
6 GJ700263260812 SCREW 2 2.6 X 8
7 GJ721271400500 METAL WASHER 1 2.7 X 14 X 0.5T
8 GJ4D04300601A1 RELAY GEAR-B 1
9 GJ703260000100 SCREW 1 SPECIAL
10 GJ560430010101 LOADING BELT 1
11 GJ4D04300901A1 TRAY LOCK GEAR 1
12 GJ4D04301001A1 RELAY GEAR-C 1
13 GJ4D04301101A1 TRAY GEAR 1
14 GJ700263260612 SCREW 3 2.6 X6
15 GJ4D04301301A2 S.SW. LEVER 1 SENSOR
16 GJ711001630100 SPRING 1 SENSOR SWITCH
17 GJ460430220101 CUSHION RUBBER 1
18 GJ460430230101 GUIDE BRACKET 1 SENSOR SWICH
19 GJ70022320812 SCREW 5 2.6 X 8
20 GJ761000190100 CUSHION 6
21 GJ4A04300101A1 TURRETTO 1
22 GJ700263261042 SCREW 1 2.6 X 10 BLACK
23 GJ560430050101 BLIND SHEET 1
24 GJ729421400300 WASHER 1 4 X 14 X 0.3T
25 GJ711001620100 SPRING 1 CHANGER GEAR
26 GJ4D04300701A1 CHANGER GEAR 1
27 GJ721311000500 WASHER 1 3.1 X 10 X 0.5T
28 GJ4B04301201A2 MAINCHASSIS 1
29 GJ381020310004 MOTOR 2 TRAY MOTOR
30 GJ4L04301901A1 SLIDE GEAR 1
31 GJ4D04300401A1 GEAR PULLEY -A 1
32 GJ560430060101 GEAR BELT 1 LOADING
33 GJ703330800202 SCREW 5 3 X 8
34 GJ711001640100 SPRING 1 CAM BRACKET
35 GJ460430160101 SWITCH LEVER 1
36 GJ4D04301401A1 UD CAM GEAR 1
37 GJ4D04301501A1 UD REDUCE GEAR 1
38 GJ700264200812 SCREW 1 2 X 10
39 GJ793312711 CHUCKING YOKE 1
40 GJ763000440100 FELT 1 35 X 65 X 0.5T
41 GJ4A04301703A1 CLAMPER 1
42 GJ383000040100 MAGNET 1
43 GJ560430070101 RAIL GUIDE 2
44 GJ4D04302001A1 ROLLER 2
45 GJ560430100101 M.C. BRACKET 1 MAIN SHASSIS
46 GJ700221300510 SCREW 4 3 X 5
47 GJ560430110101 EARTH TERMINAL 1
48 GJ761000220100 CUSHION 2 12 X 8 X 5T
(CD mechanism)
