MX-K1
3-8
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M2MM
49 GJ768564711 SCREW 1 3 X 10
50 GJ560430090101 E RING 1
51 GJA2039002001A CHANGE PLATE 1
52 GJ560430030101 C. GEAR SHAFT 1
54 -------------- SWITCH PWB 1 TURN TABLE
55 -------------- SWITCH PWB 1 TRAY SWITCH
56 -------------- SWITCH PWB 1 DISC COUNT
57 -------------- SWITCH PWB 1 PICK-UP
58 GJ302237001 RUBBER CUSHION 1
59 GJ302237011 RUBBER CUSHION 1
60 GJ4O04302101A1 MECHA BASE 1
61 GJ390170021204 SWITCH DIRECT 1
62 GJ700264261840 SCREW 1
63 GJ711001650100 SPRING 1
64 GJ711001660100 SPRING 1
65 GJ560533800101 SHIELD RING 1
66 EXL-M71-03 CD MECHA UNIT 1
67 OPTIMA-7B PICK UP ASS'Y 1
(CD mechanism)
