MX-K1

3-9

Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

C 1 GJ111067121 C.CAPACITOR 47000PF F Z 50V

C 2 GJ116222821 C.CAPACITOR 50V CH J 4.7PF

C 3 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 4 GJ116259621 C.CAPACITOR 25V F Z 0.022UF

C 5 GJ111067121 C.CAPACITOR 47000PF F Z 50V

C 6 GJ116219921 C.CAPACITOR 50V SL J 10PF

C 7 GJ116223421 C.CAPACITOR 50V CH J 12PF

C 8 GJ116223121 C.CAPACITOR 50V CH J 8.2PF

C 9 GJ111067121 C.CAPACITOR 47000PF F Z 50V

C 10 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 11 GJ111067121 C.CAPACITOR 47000PF F Z 50V

C 12 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 13 GJ270111070310 E.CAPACITOR 10V M 100UF

C 14 GJ116259621 C.CAPACITOR 25V F Z 0.022UF

C 15 GJ116259621 C.CAPACITOR 25V F Z 0.022UF

C 16 GJ270141060310 E.CAPACITOR 25V VX M 10UF

C 17 GJ116222621 M.CAPACITOR 50V CH J 3.3PF

C 18 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 19 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 20 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 21 GJ116223121 C.CAPACITOR 50V CH J 8.2PF

C 22 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 23 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 24 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 25 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 26 GJ264266822101 C.CAPACITOR 16V X M 0.0068U

C 27 GJ116228821 C.CAPACITOR 50V B K 330PF

C 28 GJ282034742415 M.CAPACITOR 50V J 0.47UF

C 29 GJ270192240310 E.CAPACITOR 50V VX M 0.22UF

C 30 GJ270193350310 E.CAPACITOR 50V VX M 3.3UF

C 33 GJ270192260310 E.CAPACITOR 50V M 22UF

C 34 GJ116259621 C.CAPACITOR 25V F Z 0.022UF

C 36 GJ282031032415 M.CAPACITOR 50V J 0.01UF

C 37 GJ282031032415 M.CAPACITOR 50V J 0.01UF

C 38 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 39 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 40 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF

C 41 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF

C 42 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 43 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 50 GJ270124760310 E.CAPACITOR 16V M 47UF

C 51 GJ116223421 C.CAPACITOR 50V CH J 12PF

C 52 GJ116223421 C.CAPACITOR 50V CH J 12PF

C 53 GJ282031052415 M.CAPACITOR 50V J 1U

C 54 GJ283103922415 P.CAPACITOR 50V K 0.0039UF

C 55 GJ116229021 C.CAPACITOR 50V B K 470PF

C 56 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 57 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 58 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 59 GJ270111070310 E.CAPACITOR 10V M 100UF

C 60 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 61 GJ116228221 C.CAPACITOR 50V B K 100PF

C 62 GJ116228221 C.CAPACITOR 50V B K 100PF

C 63 GJ116228221 C.CAPACITOR 50V B K 100PF

C 65 GJ116259621 C.CAPACITOR 25V F Z 0.022UF

C 66 GJ270124760310 E.CAPACITOR 16V M 47UF

C 101 GJ116228221 C.CAPACITOR 50V B K 100PF

C 102 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 103 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 104 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 105 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 106 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 107 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 108 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 109 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 110 GJ283108232415 P.CAPACITOR 50V K 0.082UF

C 111 GJ283108232415 P.CAPACITOR 50V K 0.082UF

C 112 GJ283105622415 P.CAPACITOR 50V K 0.0056U

C 113 GJ283101242415 P.CAPACITOR 50V K 0.12UF

C 114 GJ283101042415 P.CAPACITOR 50V K 0.1UF

C 115 GJ270111070310 E.CAPACITOR 10V M 100UF

C 116 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 201 GJ116228221 C.CAPACITOR 50V B K 100PF

C 202 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 203 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 204 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 205 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 206 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 207 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 208 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 209 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 210 GJ283108232415 P.CAPACITOR 50V K 0.082UF

C 211 GJ283108232415 P.CAPACITOR 50V K 0.082UF

C 212 GJ283105622415 P.CAPACITOR 50V K 0.0056U

C 213 GJ283101242415 P.CAPACITOR 50V K 0.12UF

C 214 GJ283101042415 P.CAPACITOR 50V K 0.1UF

C 215 GJ270111070310 E.CAPACITOR 10V M 100UF

C 216 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 301 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 302 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 303 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF

C 304 GJ116229421 C.CAPACITOR 50V B K 1000PF

C 305 GJ270121070310 E.CAPACITOR 16V VX M 100UF

C 306 GJ270114760310 E.CAPACITOR 10V M 47UF

C 307 GJ116229321 C.CAPACITOR 50V B K 820PF

C 308 GJ283101532415 P.CAPACITOR 50V K 0.015UF

C 309 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 310 GJ270121070310 E.CAPACITOR 16V VX M 100UF

C 311 GJ283106822415 P.CAPACITOR 50V K 0.0068UF

C 312 GJ282031032415 M.CAPACITOR 50V J 0.01UF

C 313 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 314 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 315 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 316 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 317 GJ270121070310 E.CAPACITOR 16V VX M 100UF

C 318 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 319 GJ270121080110 E.CAPACITOR 16V M 1000UF

C 320 GJ116228421 C.CAPACITOR 50V B K 150PF

C 321 GJ116228421 C.CAPACITOR 50V B K 150PF

C 322 GJ116228421 C.CAPACITOR 50V B K 150PF

C 323 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 324 GJ270111070310 E.CAPACITOR 10V M 100UF

C 325 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF

C 326 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 327 GJ270121060310 E.CAPACITOR 16V M 10UF

C 328 GJ270124760310 E.CAPACITOR 16V M 47UF

C 329 GJ116230621 C.CAPACITOR 16V Y M 0.01UF

C 330 GJ116228221 C.CAPACITOR 50V B K 100PF

C 331 GJ270111070310 E.CAPACITOR 10V M 100UF

C 332 GJ270124760310 E.CAPACITOR 16V M 47UF

C 333 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 334 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 335 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF

C 336 GJ270191050310 E.CAPACITOR 50V VX M 1UF

C 337 GJ270124760310 E.CAPACITOR 16V M 47UF

C 338 GJ116229421 C.CAPACITOR 50V B K 1000PF

(Main board)

Item

Parts number Parts name Area

Remarks
