JVC MX-K1 Service Manual

MX-K1
3-11
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
D 324 GJ871999133 DIODE 1SS133T77
D 602 GJ871999133 DIODE 1SS133T77
FB601 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
FF603 GJ353130170107 FFC/FPC CABLE 13PINS P=1.25MM
FW303 GJ353110190107 CABLE FLAT 11PINS L=190MM
FW601 GJ353150150107 FFC CABLE 15PINS P=1MM F
FW602 GJ354005690100 WIRE KIT 6PIN P=2.0MM
FW604 GJ353050300107 FFC/FPC CABLE 5PINS P=1.25MM
HW603 GJ156538621 HOLDER
HW606 GJ156538421 HOLDER
HW607 GJ157328721 HOLDER
IC 1 GJ313011361106 IC LA1823 DIP
IC 2 GJ313070221000 IC LC72136N
IC101 GJ313070541318 IC
A
TDA7440D
IC102 GJ313010023103 IC BA15218 DIP
IC401 GJ313080521101 IC TA8189N
IC402 GJ313070041101 IC TC74HC4094AP
IC601 GJ313060841223 IC MN662748RPMFA
IC611 GJ313020851323 IC AN22000A
IC621 GJ313050221003 IC BA5936S
J 1 GJ342040190113 SPK JACK 4PIN BLACK
(
MS
J 301 GJ342030140109 RCA JACK D=8.2MM 4PINS
L 1 GJ241112292102 INDUCTOR 2.2UH 5%
Q
40
L 2 GJ320130010103 COIL MW RF BLOCK TK
L 3 GJ320020260109 COIL FM RF
(
V
Q
C1505
L 4 GJ320020270109 COIL FM OSC
L 5 GJ141052131 INDUCTOR 100UH 5%
Q
40
L 6 GJ241112202102 INDUCTOR 22UH 10%
Q
40
L 7 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 50 GJ241112212102 INDUCTOR 220UH 10%
Q
40
L 301 GJ320060040105 BIAS COIL BLACK R0655OD12
L 302 GJ141039721 FERRITE BEAD 1.1UH
L 303 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 304 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 305 GJ241111002102 INDUCTOR 10UH 5%
Q
40
L 306 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 307 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 601 GJ241111002102 INDUCTOR 10UH 5%
Q
40
LC 1 GJ123671122 B.P.FILTER B.P.FILTER GFMB
M 1 GJ381020310004 TRAY MOTOR
M 2 GJ176336711 TUNERBT.MOTOR
P-SW GJ390070031204 PICK UP SWITCH DOUBLE SWING
Q
1 GJ312030141210 TRANSISTOR KTC3194
Q
2 GJ312030152210 TRANSISTOR KTC3195
(
Y
)
Q
3 GJ872990437 TRANSISTOR DTC114YS
Q
4 GJ872990437 TRANSISTOR DTC114YS
Q
5 GJ872903720 TRANSISTOR KRA107M
Q
6 GJ872990437 TRANSISTOR DTC114YS
Q
7 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
8 GJ312011231210 TRANSISTOR KTA1267Y
Q
101 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
201 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
301 GJ312030131210 TRANSISTOR KTC3200
(
GR
)
Q
302 GJ872903720 TRANSISTOR KRA107M
Q
303 GJ872903686 TRANSISTOR KTC3203Y
Q
304 GJ312011231210 TRANSISTOR KTA1267Y
Q
305 GJ872903003 TRANSISTOR DTC144ESA
Q
308 GJ872903003 TRANSISTOR DTC144ESA
Q
309 GJ872904076 TRANSISTOR KTA1273
(
Y
)
Q
310 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
311 GJ872904076 TRANSISTOR KTA1273
(
Y
)
Q
312 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
313 GJ872904076 TRANSISTOR KTA1273
(
Y
)
Q
315 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
316 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
317 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
318 GJ312030111210 TRANSISTOR KTC3199TPGR
Q
319 GJ312011231210 TRANSISTOR KTA1267Y
Q
321 GJ872990437 TRANSISTOR DTC114YS
Q
401 GJ872992241 TRANSISTOR 2SD2144STPUVW
Q
402 GJ872992241 TRANSISTOR 2SD2144STPUVW
Q
501 GJ872992241 TRANSISTOR 2SD2144STPUVW
Q
502 GJ872992241 TRANSISTOR 2SD2144STPUVW
Q
601 GJ312011231210 TRANSISTOR KTA1267Y
Q
602 GJ872990437 TRANSISTOR DTC114YS
R 1 GJ250031522199 CARBON RESISTOR 1/4WM J 1.5K
R 2 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 3 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 4 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 5 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 6 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 7 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 8 GJ250031002199 CARBON RESISTOR 1/4WM J 10
R 9 GJ250031002199 CARBON RESISTOR 1/4WM J 10
R 10 GJ250034712199 CARBON RESISTOR 1/4WM J 470
R 11 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 12 GJ250034742199 CARBON RESISTOR 1/4WM J 470K
R 13 GJ250035602199 CARBON RESISTOR 1/4WM J 56
R 14 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 15 GJ250031532199 CARBON RESISTOR 1/4WM J 150
R 16 GJ250032202199 CARBON RESISTOR 1/4WM J 22
R 17 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 18 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R 19 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 20 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 21 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 22 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 23 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R 24 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R 25 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 26 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 27 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 51 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 52 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 53 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 54 GJ250031822199 CARBON RESISTOR 1/4WM J 1.8K
R 55 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 56 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 57 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 58 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 59 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 60 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 61 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 62 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 63 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 64 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 65 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 66 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 67 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 68 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 69 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 70 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 71 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 72 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 73 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 74 GJ250033302199 CARBON RESISTOR
A
1/4WM J 33
Item
Parts number Parts name Area
Remarks
A
(Main board)
