JVC MX-K1 Service Manual

MX-K1
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 101 GJ250033932199 CARBON RESISTOR 1/4WM J 39K
R 102 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 103 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R 104 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 105 GJ250031242199 CARBON RESISTOR 1/4WM J 120K
R 106 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 107 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 108 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 109 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 110 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 111 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 112 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R 113 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 114 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 115 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 201 GJ250033932199 CARBON RESISTOR 1/4WM J 39K
R 202 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 203 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R 204 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 205 GJ250031242199 CARBON RESISTOR 1/4WM J 120K
R 206 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 207 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 208 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 209 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 211 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 212 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R 213 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 214 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 215 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 301 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 302 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 303 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 304 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 305 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 306 GJ250031052199 CARBON RESISTOR 1/4WM J 1M
R 307 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 308 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 309 GJ250031002199 CARBON RESISTOR 1/4WM J 10
R 310 GJ250033302199 CARBON RESISTOR 1/4WM J 33
R 311 GJ250034792199 CARBON RESISTOR 1/4WM J 4.7
R 312 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 316 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 317 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 319 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 320 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 321 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 322 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 323 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 324 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 325 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 328 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 329 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 330 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 331 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 332 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 333 GJ250031512199 CARBON RESISTOR 1/4WM J 150
R 334 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 335 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 336 GJ250031512199 CARBON RESISTOR 1/4WM J 150
R 337 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 338 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 339 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 340 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 341 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 344 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 345 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 346 GJ250034702199 CARBON RESISTOR 1/4WM J 47
R 347 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 348 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 349 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 350 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 351 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 352 GJ250031532199 CARBON RESISTOR 1/4WM J 150
R 353 GJ250031812199 CARBON RESISTOR 1/4WM J 180
R 354 GJ250038212199 CARBON RESISTOR 1/4WM J 820
R 355 GJ250033302199 CARBON RESISTOR 1/4WM J 33
R 356 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 357 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 358 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 359 GJ250034712199 CARBON RESISTOR 1/4WM J 470
R 361 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 362 GJ255052291611 FUSE RESISTOR 1/4W J 2.2 OHM
R 363 GJ250034712199 CARBON RESISTOR 1/4WM J 470
R 364 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 365 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 366 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 401 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 402 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 404 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 405 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R 406 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R 407 GJ250036832199 CARBON RESISTOR 1/4WM J 68K
R 408 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 409 GJ250031542199 CARBON RESISTOR 1/4WM J 150K
R 410 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 412 GJ250031822199 CARBON RESISTOR 1/4WM J 1.8K
R 413 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 414 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 415 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 416 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 417 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 418 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 421 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 422 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 501 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 502 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 504 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 505 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R 506 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R 507 GJ250036832199 CARBON RESISTOR 1/4WM J 68K
R 508 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 509 GJ250031542199 CARBON RESISTOR 1/4WM J 150K
R 510 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 512 GJ250031822199 CARBON RESISTOR 1/4WM J 1.8K
R 513 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 514 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 515 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 516 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 517 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 518 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 521 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 522 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 601 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R 602 GJ250031212199 CARBON RESISTOR 1/4WM J 120
R 603 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 604 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
Item
Parts number Parts name Area
Remarks
A
(Main board)
