JVC MX-K1 Service Manual

MX-K1
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 605 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 611 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 615 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 616 GJ250033932199 CARBON RESISTOR 1/4WM J 39K
R 617 GJ250031052199 CARBON RESISTOR 1/4WM J 1M
R 618 GJ250036832199 CARBON RESISTOR 1/4WM J 68K
R 619 GJ250031012199 CARBON RESISTOR 1/4WM J 100
R 621 GJ250036832199 CARBON RESISTOR 1/4WM J 68K
R 622 GJ250036832199 CARBON RESISTOR 1/4WM J 68K
R 623 GJ250031242199 CARBON RESISTOR 1/4WM J 120K
R 625 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 628 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R 629 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 630 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 631 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 632 GJ250031002199 CARBON RESISTOR 1/4WM J 10
R 633 GJ250031002199 CARBON RESISTOR 1/4WM J 10
R 634 GJ250031202199 CARBON RESISTOR 1/4WM J 12
R 635 GJ250033932199 CARBON RESISTOR 1/4WM J 39K
R 636 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R 637 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 638 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 639 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 640 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 642 GJ250031542199 CARBON RESISTOR 1/4WM J 150K
R 643 GJ250035642199 CARBON RESISTOR 1/4WM J 560K
R 644 GJ250031842199 CARBON RESISTOR 1/4WM J 180
R 645 GJ250032742199 CARBON RESISTOR 1/4WM J 270
R 646 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R 647 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 648 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 649 GJ250032292199 CARBON RESISTOR 1/4WM J 2.2
R 650 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 651 GJ250032732199 CARBON RESISTOR 1/4WM J 27K
R 652 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 653 GJ250031222199 CARBON RESISTOR 1/4WM J 1.2K
R 654 GJ250031232199 CARBON RESISTOR 1/4WM J 12K
R 655 GJ250032432199 CARBON RESISTOR 1/4WM J 24K
R 656 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R 657 GJ250033922199 CARBON RESISTOR 1/4WM J 3.9K
R 659 GJ250031042199 CARBON RESISTOR 1/4WM J 100K
R 660 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 661 GJ250033322199 CARBON RESISTOR 1/4WM J 3.3K
R 662 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 663 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 664 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 665 GJ250036822199 CARBON RESISTOR 1/4WM J 6.8K
R 666 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 667 GJ250031832199 CARBON RESISTOR 1/4WM J 18K
R 668 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R 669 GJ250032712199 CARBON RESISTOR 1/4WM J 270
R 670 GJ250033942199 CARBON RESISTOR 1/4WM J 390K
R 671 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R 672 GJ250035642199 CARBON RESISTOR 1/4WM J 560K
R 673 GJ250035642199 CARBON RESISTOR 1/4WM J 560K
R 675 GJ250038222199 CARBON RESISTOR 1/4WM J 8.2K
R210R GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
SW703 GJ390170021204 SWITCH DETECTOR SWITCH
SW704 GJ390170021204 SWITCH 120688
T 1 GJ321000720109 IFT 7MM BLACK PCFA
T-SW GJ390070031204 TRAY SWITCH DOUBLE SWING SW
W 603 GJ354005930100 WIRE KIT
W 606 GJ353030180107 CABLE FLAT 3PIN P=2MM L=1
W 607 GJ353020120207 FLAT CABLE
W 608 GJ354005380100 WIRE KIT 2PINS P=2.0MM L
WK307 GJ354005940100 WIRE KIT 3PINS P=2MM
WK308 GJ354005950100 WIRE KIT
X 1 GJ361000130003 X'TAL 75KHZ +/20PPM
(
V
X 601 GJ361000400009 CRYSTAL 16.9344MHZ HC49
Item
Parts number Parts name Area
Remarks
A
(Main board)
