JVC MX-K1 Service Manual

MX-K1
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
C 701 GJ264291042101 C.CAPACITOR 0.1MF FF 50V
C 702 GJ270112270310 E.CAPACITOR 10V VX M 220UF
C 703 GJ270112270310 E.CAPACITOR 10V VX M 220UF
C 704 GJ270112270310 E.CAPACITOR 10V VX M 220UF
C 705 GJ116229421 C.CAPACITOR 50V B K 1000PF
C 706 GJ116229421 C.CAPACITOR 50V B K 1000PF
C 707 GJ116221321 C.CAPACITOR 50V SL J 39PF
C 708 GJ116221121 C.CAPACITOR 50V SL J 33PF
C 709 GJ116220721 C.CAPACITOR 50V SL J 22PF
C 710 GJ116220721 C.CAPACITOR 50V SL J 22PF
C 711 GJ116220721 C.CAPACITOR 50V SL J 22PF
C 712 GJ116220721 C.CAPACITOR 50V SL J 22PF
C 713 GJ264291042101 C.CAPACITOR 0.1MF FF 50V
C 714 GJ116230621 C.CAPACITOR 16V Y M 0.01UF
C 715 GJ116229421 C.CAPACITOR 50V B K 1000PF
C 716 GJ270114760310 E.CAPACITOR 10V M 47UF
C 717 GJ264291042101 C.CAPACITOR 0.1MF FF 50V
C 718 GJ270192260310 E.CAPACITOR 50V M 22UF
C 719 GJ270192260310 E.CAPACITOR 50V M 22UF
C 723 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 740 GJ116228221 C.CAPACITOR 50V B K 100PF
CN701 GJ340021110102 CONNECTOR P=1.25MM RA 11
CN702 GJ340021200102 CONNECTOR P=1.25MM RA 20
CN703 GJ340021210102 CONNECTOR P=1.25MM RA 21P
C1001 GJ116230621 C.CAPACITOR 16V Y M 0.01UF
C1002 GJ116230621 C.CAPACITOR 16V Y M 0.01UF
C1051 GJ264141022199 C.CAPACITOR 50V B K 1000PF
C1052 GJ264141022199 C.CAPACITOR 50V B K 1000PF
C1053 GJ264141022199 C.CAPACITOR 50V B K 1000PF
C1054 GJ264141022199 C.CAPACITOR 50V B K 1000PF
D 701 GJ871999133 DIODE 1SS133T77
D 702 GJ871999133 DIODE 1SS133T77
D 703 GJ871999133 DIODE 1SS133T77
D 705 GJ871999133 DIODE 1SS133T77
FL701 GJ373020041000 FL DISPLAY DISPLAY FL BJ82
FW101 GJ353040400107 FUSE RESISTOR 4PINS P=2.5 L=4
FW701 GJ353100200107 CABLE FLAT P=2.54 10PINS U
FW702 GJ353200180107 FFC CABLE FFC/FPC L=180M
FW703 GJ353210180107 FFC CABLE FFC/FPC L=180M
IC701 GJ313010662223 IC MN101C35DYC
IC702 GJ313040901006 IC SPS4401E
(
IR SEN
J 101 GJ342010300113 H/P JACK D=3.5MM
(
MSJ03
L 701 GJ241112202102 INDUCTOR 10UH 5%
Q
40
L 702 GJ241111002102 INDUCTOR 10UH 5%
Q
40
L 703 GJ141039721 FERRITE BEAD 1.1UH
(
F.B
)
L 707 GJ241111002102 INDUCTOR 10UH 5%
Q
40
LED01 GJ374301012101 LED
L1051 GJ241114702102 INDUCTOR INDUCTOR 47UH 1
L1052 GJ241114702102 INDUCTOR INDUCTOR 47UH 1
L1053 GJ371010100005 FERRITE BEAD LGK0305TBA
Q
701 GJ312030111210 TRANSISTOR KTC3199TP
Q
702 GJ312030111210 TRANSISTOR KTC3199TP
Q
703 GJ312030111210 TRANSISTOR KTC3199TP
Q
704 GJ312030152210 TRANSISTOR KTC3195
(
Y
)
Q
705 GJ312030152210 TRANSISTOR KTC3195
(
Y
)
(
TAP
Q
706 GJ312011231210 TRANSISTOR KTA1267Y
Q
707 GJ872990437 TRANSISTOR DTC114YS
Q
711 GJ312011171210 TRANSISTOR KRA102M
Q
713 GJ872990437 TRANSISTOR DTC114YS
Q
714 GJ312030111210 TRANSISTOR KTC3199TP
Q
715 GJ312030111210 TRANSISTOR KTC3199TP
R 138 GJ250056812510 CARBON RESISTOR
R 238 GJ250056812510 CARBON RESISTOR
R 701 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R 702 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R 703 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R 704 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 705 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 706 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 707 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 709 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 710 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 711 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 712 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 713 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 714 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 715 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 716 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 717 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 718 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 719 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 720 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 721 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 722 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 723 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 724 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 725 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 726 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 727 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 728 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 729 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 730 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 731 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 732 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 733 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 734 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 736 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 737 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 738 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 739 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 740 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 741 GJ250033312199 CARBON RESISTOR 1/4WM J 330
R 742 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 743 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 744 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R 745 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 746 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 747 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 748 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 749 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 750 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 751 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 752 GJ250034722199 CARBON RESISTOR 1/4WM J 4.7K
R 753 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 754 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 755 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 756 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 757 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 758 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 761 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 762 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 763 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 764 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 768 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 769 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 770 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
(Control board)
Item
Parts number Parts name Area
Remarks
A
