JVC MX-K1 Service Manual

MX-K1
3-15
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
R 772 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 773 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 774 GJ250031822199 CARBON RESISTOR 1/4WM J 1.8K
R 775 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 776 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 777 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 778 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 779 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 780 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 781 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 782 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 783 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R 784 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 785 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 786 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 787 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R 788 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 789 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R 790 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 791 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R 792 GJ250033312199 CARBON RESISTOR 1/4WM J 330
RA701 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA702 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA703 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA704 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA705 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA706 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA707 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA708 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA709 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA710 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA711 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA712 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA713 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA714 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA715 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA716 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA717 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA718 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA719 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA720 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA721 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA722 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA723 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA724 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA725 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA726 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA727 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA728 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
RA729 GJ250032242199 CARBON RESISTOR 1/4WM J 220K
R1001 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1002 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1003 GJ250038212199 CARBON RESISTOR 1/4WM J 820
R1004 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1005 GJ250031522199 CARBON RESISTOR 1/4WM J 1.5K
R1008 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1009 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1010 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1011 GJ250038212199 CARBON RESISTOR 1/4WM J 820
R1012 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1013 GJ250031522199 CARBON RESISTOR 1/4WM J 1.5K
R1014 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R1015 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R1017 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1018 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1019 GJ250038212199 CARBON RESISTOR 1/4WM J 820
R1020 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1021 GJ250031522199 CARBON RESISTOR 1/4WM J 1.5K
R1022 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R1023 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R1024 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R1025 GJ250031232199 CARBON RESISTOR 1/4WM J 12K
R1026 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1027 GJ250036812199 CARBON RESISTOR 1/4WM J 680
R1028 GJ250038212199 CARBON RESISTOR 1/4WM J 820
R1029 GJ250031522199 CARBON RESISTOR 1/4WM J 1.5K
R1029 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1031 GJ250032222199 CARBON RESISTOR 1/4WM J 2.2K
R1032 GJ250032722199 CARBON RESISTOR 1/4WM J 2.7K
R1033 GJ250035622199 CARBON RESISTOR 1/4WM J 5.6K
R1034 GJ250031232199 CARBON RESISTOR 1/4WM J 12K
R1037 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R1038 GJ250032232199 CARBON RESISTOR 1/4WM J 22K
R1039 GJ250031242199 CARBON RESISTOR 1/4WM J 120K
R1040 GJ250031242199 CARBON RESISTOR 1/4WM J 120K
R1041 GJ250035632199 CARBON RESISTOR 1/4WM J 56K
R1042 GJ250035632199 CARBON RESISTOR 1/4WM J 56K
R1043 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1047 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1048 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R1060 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1061 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1062 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R1063 GJ250032212199 CARBON RESISTOR 1/4WM J 220
R1064 GJ250031232199 CARBON RESISTOR 1/4WM J 12K
R1065 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1066 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R1067 GJ250031022199 CARBON RESISTOR 1/4WM J 1K
R1068 GJ250031032199 CARBON RESISTOR 1/4WM J 10K
R1069 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1070 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1071 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1072 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1073 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1074 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
R1075 GJ250034732199 CARBON RESISTOR 1/4WM J 47K
S1001 GJ390110181120 TACT SWITCH
(
POWER
)
SW101 GJ299000570003 VR ENCODER VR EVEKD2F3024B
S1002 GJ390110181120 TACT SWITCH
(
TAPE
)
S1003 GJ390110181120 TACT SWITCH
(
AUX
)
S1004 GJ390110181120 TACT SWITCH
(
BAND
)
S1005 GJ390110181120 TACT SWITCH
(
CANCEL
)
S1006 GJ390110181120 TACT SWITCH
(
SET
)
S1007 GJ390110181120 TACT SWITCH CD
)
S1008 GJ390110181120 TACT SWITCH
(
CD1
)
S1009 GJ390110181120 TACT SWITCH
(
CD2
)
S1010 GJ390110181120 TACT SWITCH
(
CD3
)
S1011 GJ390110181120 TACT SWITCH
(
EJECT
)
S1012 GJ390110181120 TACT SWITCH
(
DISC
)
S1013 GJ390110181120 TACT SWITCH
(
DECK A/B
)
S1014 GJ390110181120 TACT SWITCH
(
TIM/CLK
)
S1015 GJ390110181120 TACT SWITCH
(
STOP
)
S1016 GJ390110181120 TACT SWITCH
(
TUN+
)
S1017 GJ390110181120 TACT SWITCH
(
TUN
)
S1018 GJ390110181120 TACT SWITCH
(
PRESET
)
S1019 GJ390110181120 TACT SWITCH
(
PRESET+
)
Item
Parts number Parts name Area
Remarks
A
(Control board)
