3-10
Power board
Block No. [0][2]
EC438 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC439 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC440 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC441 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC442 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC443 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC444 OW06-71476-20 E CAPACITOR 47uF 16V KB2
EC445 OW06-70227-20 E CAPACITOR 220uF 10V KB2
JR10 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR11 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR12 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR13 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR14 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR15 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR16 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR17 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR18 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR19 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR20 OW07-76000-30 C RESISTOR 0 ohm 1/16W KB2
JR21 OW07-76000-30 C RESISTOR 0 ohm 1/16W KB2
JR22 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR23 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR24 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR25 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR26 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR27 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR28 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR29 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR31 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR32 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR33 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR34 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR35 OW07-75001-05F C RESISTOR 0 ohm 1/8W KB2
JR37 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR38 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR39 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR40 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR41 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR42 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR43 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR44 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR45 OW07-76000-30 C RESISTOR 0 ohm 1/16W
JR47 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR48 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR49 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR50 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR51 OW07-75001-05F C RESISTOR 0 ohm 1/8W
JR52 OW07-75001-05F C RESISTOR 0 ohm 1/8W
MC102 OW05-72822-10 M CAPACITOR 0.0082uF
MC103 OW05-72822-10 M CAPACITOR 0.0082uF
MC104 OW05-72472-10 M CAPACITOR 0.0047uF
MC105 OW05-70221-05 C CAPACITOR 220pF
MC106 OW05-72682-10 M CAPACITOR 0.0068uF
MC107 OW05-72102-10 M CAPACITOR 0.001uF
MC108 OW05-72102-10 M CAPACITOR 0.001uF
MC109 OW05-72102-10 M CAPACITOR 0.001uF
MC110 OW05-72102-10 M CAPACITOR 0.001uF
MC111 OW05-72102-10 M CAPACITOR 0.001uF
MC401 OW05-72472-10 M CAPACITOR 0.0047uF
MC402 OW05-72472-10 M CAPACITOR 0.0047uF
P1-P2 OW05-77104-82 C CAPACITOR Axial 0.1uF KB2
P3-P4 OW05-77104-82 C CAPACITOR Axial 0.1uF KB2
X300 OW09-50720-80 C RESONATOR ZTA7.2MT
X301 OW04-32768-80 CRYSTAL 32.768MHz
X401 OW04-16934-70 CRYSTAL 16.9344MHz
XXXXX OW20-51061-20 CONNECTOR WIRE 6P To CD Pick up
XXXXX OW20-61030-00 CONNECTOR WIRE 3P For Play header
XXXXX OW20-61070-00 CONNECTOR WIRE 7P For R/P Header
XXXXX OW20-61073-11 CONNECTOR WIRE 7P To Power PCB
XXXXX OW39-00013-80 HEAT SINK CDT13 for U403
XXXXX OW11-01002-00 MAIN PCB
XXXXX OW25-61135-80 FFC CABLE 16P
XXXXX OW25-61260-80 CABLE 13P
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC801 STK402-050 IC(HYBRID) OW03-40205-00
U802 L7809CV IC OW03-07809-85
U803 L7806CV IC OW03-07806-84
Q801 8050 TRANSISTOR OW01-08050-80
Q802 2SB1243 TRANSISTOR OW01-01243-80
Q803 8050 TRANSISTOR OW01-08050-80
Q812 8050 TRANSISTOR OW01-08050-80
Q813 8050 TRANSISTOR OW01-08050-80
Q860 8050 TRANSISTOR OW01-08050-80
Q861 8050 TRANSISTOR OW01-08050-80
Q862 8550 TRANSISTOR OW01-08550-86
Q864 8050 TRANSISTOR OW01-08050-80
Q865 8050 TRANSISTOR OW01-08050-80
Q867 8050 TRANSISTOR OW01-08050-80
Q868 8550 TRANSISTOR OW01-08550-86
Q869 8050 TRANSISTOR OW01-08050-80
Q870 8050 TRANSISTOR OW01-08050-80
Q871 8050 TRANSISTOR OW01-08050-80
D1 1N4148 DIODE OW02-04148-81
D2 1N4148 DIODE OW02-04148-81
D800 1N4148 DIODE OW02-04148-81
D803 1N4148 DIODE OW02-04148-81
D804 1N4001 DIODE OW02-04001-81
D806 1N4001 DIODE OW02-04001-81
D807 1N4001 DIODE OW02-04001-81
D808 1N4001 DIODE OW02-04001-81
D809 1N4001 DIODE OW02-04001-81
D845 1N4001 DIODE OW02-04001-81
D846 1N4001 DIODE OW02-04001-81
D849 1N5402 DIODE OW02-05402-80
D850 1N5402 DIODE OW02-05402-80
D851 1N5402 DIODE OW02-05402-80
D852 1N5402 DIODE OW02-05402-80
D864 1N4001 DIODE OW02-04001-81
D865 1N4148 DIODE OW02-04148-81
ZD822 13V0.5W Z DIODE OW02-50130-80
ZD823 4.7V0.5W Z DIODE OW02-50047-80
C802 OW05-73221-00 C CAPACITOR 220pF
C803 OW05-73050-05 C CAPACITOR 5pF
C804 OW05-73474-00 C CAPACITOR 0.47uF
C805 OW05-73474-00 C CAPACITOR 0.47uF
C806 OW05-73050-05 C CAPACITOR 5pF
C807 OW05-73102-00 C CAPACITOR 1000pF
C808 OW05-73102-00 C CAPACITOR 1000pF
C814 OW05-73561-00 C CAPACITOR 560pF
C815 OW05-73561-00 C CAPACITOR 560pF
C816 OW05-73221-00 C CAPACITOR 220pF
C821 OW05-73104-00 C CAPACITOR 0.1uF
C839 OW05-73103-00 C CAPACITOR 0.01uF
C842 OW05-73103-00 C CAPACITOR 0.01uF
C860 OW05-73474-00 C CAPACITOR 0.47uF
C861 OW05-73474-00 C CAPACITOR 0.47uF
C862 OW05-73105-06F C CAPACITOR 1uF
C863 OW05-73105-06F C CAPACITOR 1uF
C865 OW05-73104-00 C CAPACITOR 0.1uF
C866 OW05-73104-00 C CAPACITOR 0.1uF
C901 OW05-70103-05 C CAPACITOR 0.01uF KB1
C902 OW05-70103-05 C CAPACITOR 0.01uF KB1
R801 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R802 OW07-75102-50 C RESISTOR 1 Kohm 1/8W
R803 OW07-75563-50 C RESISTOR 56 Kohm 1/8W
R805 OW07-75103-50 C RESISTOR 10 Kohm 1/8W
R806 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R807 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R809 OW07-75047-10 C RESISTOR 4.7 ohm 1W
R810 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R812 OW07-75010-50 C RESISTOR 1 ohm 1/8W
R815 OW07-74031-40 C RESISTOR 0.33 ohm 1W
R816 OW07-70101-11 C RESISTOR 100 ohm 1/2W
R817 OW07-75223-50 C RESISTOR 22 Kohm 1/8W
