AMP board
Block No. [0][4]
R902 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W J C
L BI201323010101 TERMINAL 1P
L901 BI2601102 LINE FILTER
CW902 BI12P40302V CONNECTOR WIRE 4P for AMP CN902
CW903 BI12P90071V CONNECTOR WIRE 9P for AMP CN903
N BI201323010101 TERMINAL 1P
PT902 BI211011098001 POWER TRANS EI28
RL901 BI8RL00171V RELAY
DC9V 250mW
KTC3199GR
S901 BI805221X POWER SWITCHES SDKGA41301
XXXXX BI11W080H2Y WIRE RED UL1672
XXXXX BI11W080H3Y WIRE ORANGE UL1672
XXXXX BI11W080H4Y WIRE YELLOW UL1672
XXXXX BI11W080H8Y WIRE GRAY UL1672
XXXXX BI11W080H6Y WIRE BLUE UL1672
XXXXX BI11W080H9Y WIRE WHITE UL1672
XXXXX BI18A00181 FERRITE BEAD 25X15X15
Symbol No.
Part No. Part Name Description Local
IC601 STK433-060-E IC BI116921V
IC602 78L05 IC BI101851
Q602 2SC3052 TRANSISTOR BI2SC3052FA013H
Q603 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q604 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q605 2SC3052 TRANSISTOR BI2SC3052FA013H
Q606 2SC3052 TRANSISTOR BI2SC3052FA013H
Q607 KTA1273 TRANSISTOR BI2KTA1273P0008
Q608 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q609 2SC3052 TRANSISTOR BI2SC3052FA013H
Q610 2SC3052 TRANSISTOR BI2SC3052FA013H
Q611 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q612 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q613 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q614 2SC3052 TRANSISTOR BI2SC3052FA013H
Q615 2SC3052 TRANSISTOR BI2SC3052FA013H
Q616 2SC3052 TRANSISTOR BI2SC3052FA013H
Q617 2SC3052 TRANSISTOR BI2SC3052FA013H
Q618 2SC3052 TRANSISTOR BI2SC3052FA013H
Q619 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q620 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q621 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q622 2SC3052 TRANSISTOR BI2SC3052FA013H
Q623 2SC3052 TRANSISTOR BI2SC3052FA013H
Q624 2SC3052 TRANSISTOR BI2SC3052FA013H
Q627 2DTC114YS TRANSISTOR BI2DTC114YSP002
Q628 2DTC114YS TRANSISTOR BI2DTC114YSP002
Q629 2DTC114YS TRANSISTOR BI2DTC114YSP002
Q630 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q631 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q632 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q633 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q634 2SC3052 TRANSISTOR BI2SC3052FA013H
Q635 2SA1235F TRANSISTOR BI2SA1235FA012H
Q636 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
D601 1N4001 DIODE BI31N4001M0006
D602 1N4001 DIODE BI31N4001M0006
D603 1N4001 DIODE BI31N4001M0006
D605 1N4001 DIODE BI31N4001M0006
D606 1N4001 DIODE BI31N4001M0006
D607 UZ12BSC Z DIODE BI3UZ12BSCM000V
D609 UZ30BSA Z DIODE BI3UZ30BSDM000
D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
D613 1N4001 DIODE BI31N4001M0006
D615 RS402M SELEN RECTIFIER BI3RS402M1
D616 1SS133 FR DIODE BI31SS133M000V7
Symbol No.
Part No. Part Name Description Local
D617 1SS133 FR DIODE BI31SS133M000V7
D618 1SS133 FR DIODE BI31SS133M000V7
D619 1SS133 FR DIODE BI31SS133M000V7
D621 1SS133 FR DIODE BI31SS133M000V7
D622 1SS133 FR DIODE BI31SS133M000V7
D623 1SS133 FR DIODE BI31SS133M000V7
D624 1SS133 FR DIODE BI31SS133M000V7
D625 1SS133 FR DIODE BI31SS133M000V7
D626 1SS133 FR DIODE BI31SS133M000V7
D628 1SS133 FR DIODE BI31SS133M000V7
D629 1SS133 FR DIODE BI31SS133M000V7
D632 1SS133 FR DIODE BI31SS133M000V7
D633 MC2836 DIODE BI3MC2836A002H
D634 MC2838 DIODE BI3MC2838A002
D635 1SS133 FR DIODE BI31SS133M000V7
C601 BICM682101KP01 M CAPACITOR 6800pF 100V
C602 BICM682101KP01 M CAPACITOR 6800pF 100V
C603 BICE477250MP01 E CAPACITOR 470uF 25V
C604 BICE47835M6Y1 E CAPACITOR 4700uF 35V
C605 BICE47835M6Y1 E CAPACITOR 4700uF 35V
C607 BICE107250MP01 E CAPACITOR 100uF 25V
C608 BICC104500KA04 C CAPACITOR 0.1uF 50V
C609 BICE107160MP01 E CAPACITOR 100uF 16V
C610 BICE107630MP01 E CAPACITOR 100uF 63V
C611 BICE226500MP01 E CAPACITOR 22uF 50V
C612 BICC103500KA04 C CAPACITOR 0.01uF 50V
C613 BICE107630MP01 E CAPACITOR 100uF 63V
C614 BICE106500MP01 E CAPACTIOR 10uF 50V
C615 BICC103500KA04 C CAPACITOR 0.01uF 50V
C616 BICE477160MP01 E CAPACITOR 470uF 16V
C617 BICM682101KP01 M CAPACITOR 6800pF 100V
C618 BICM682101KP01 M CAPACITOR 6800pF 100V
C619 BICE336160MP01 E CAPACITOR 33uF 16V
C620 BICE476160MP01 E CAPACITOR 47uF 16V
C621 BICM682101KP01 M CAPACITOR 6800pF 100V
C622 BICM682101KP01 M CAPACITOR 6800pF 100V
C623 BICE33856M1Y E CAPACITOR 3300uF 56V
C624 BICE33856M1Y E CAPACITOR 3300uF 56V
C625 BICC470500JA04 C CAPACITOR 47pF 50V
C626 BICC470500JA04 C CAPACITOR 47pF 50V
C633 BICE107630MP01 E CAPACITOR 100uF 63V
C634 BICE107630MP01 E CAPACITOR 100uF 63V
C635 BICE106500MP01 E CAPACTIOR 10uF 50V
C636 BICE106500MP01 E CAPACTIOR 10uF 50V
C637 BICC030500CA04 C CAPACITOR 3pF 50V
C638 BICC030500CA04 C CAPACITOR 3pF 50V
C639 BICC471500KA04 C CAPACITOR 470pF 50V
C640 BICC471500KA04 C CAPACITOR 470pF 50V
C641 BICE225500MP01 E CAPACITOR 2.2uF 50V
C642 BICE225500MP01 E CAPACITOR 2.2uF 50V
C645 BICM104101KP01 M CAPACITOR 0.1uF 100V
C646 BICM104101KP01 M CAPACITOR 0.1uF 100V
C647 BICM104101KP01 M CAPACITOR 0.1uF 100V
C648 BICM104101KP01 M CAPACITOR 0.1uF 100V
C649 BICC151500JA04 C CAPACITOR 150pF 50V
C650 BICE107160MP01 E CAPACITOR 100uF 16V
C651 BICC223500KA04 C CAPACITOR 0.022uF 50V
C652 BICE226500MP01 E CAPACITOR 22uF 50V
C653 BICC104500KA04 C CAPACITOR 0.1uF 50V
C654 BICC104500KA04 C CAPACITOR 0.1uF 50V
C655 BICC153500KA04 C CAPACITOR 0.015uF 50V
C656 BICC153500KA04 C CAPACITOR 0.015uF 50V
C662 BICE106250MP01 E CAPACITOR 10uF 25V
C663 BICE107630MP01 E CAPACITOR 100uF 63V
C664 BICE227160MP01 E CAPACITOR 220uF 16V
C665 BICE477100MP01 E CAPACITOR 470uF 10V
C666 BICE107250MP01 E CAPACITOR 100uF 25V
C668 BICC104500KA04 C CAPACITOR 0.1uF 50V
C669 BICE475500MP01 E CAPACITOR 4.7uF 50V
C670 BICE226160MP01 E CAPACITOR 22uF 16V
C671 BICE106500MP01 E CAPACTIOR 10uF 50V
C672 BICE106500MP01 E CAPACTIOR 10uF 50V
C676 BICE107630MP01 E CAPACITOR 100uF 63V
R600 BIRC8210105A00 C RESISTOR 820
Ω
1/10W
R601 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R603 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
Symbol No.
Part No. Part Name Description Local
