3-13
Wiring
Block No. [0][5]
R604 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R605 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R606 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R607 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R608 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R609 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R610 BIRC1540105A00 C RESISTOR 150K
Ω
1/10W
R611 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R612 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R613 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R614 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R615 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R616 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R617 BIRC6810105A00 C RESISTOR 680
Ω
1/10W
R618 BIRC1230105A00 C RESISTOR 12K
Ω
1/10W
R619 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R620 BIRC5620085M00 C RESISTOR 5.6K
Ω
1/8W J
R621 BIRC6810105A00 C RESISTOR 680
Ω
1/10W
R623 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R624 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R625 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R626 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R627 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R628 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R629 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R630 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R631 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R632 BIRM002220VP M RESISTOR 0.22
Ω
2W
R634 BIRM002220VP M RESISTOR 0.22
Ω
2W
R636 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R637 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R638 BIRC2230045M00 C RESISTOR 22K
Ω
1/4W
R639 BIRC2230045M00 C RESISTOR 22K
Ω
1/4W
R640 BIRC0470045M00 C RESISTOR 4.7
Ω
1/4W J
R641 BIRC0470045M00 C RESISTOR 4.7
Ω
1/4W J
R642 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R643 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R648 BIRC0470045M00 C RESISTOR 4.7
Ω
1/4W J
R649 BIRC0470045M00 C RESISTOR 4.7
Ω
1/4W J
R650 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R651 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R652 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R653 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R654 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R655 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R656 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R657 BIRC6840105A00 C RESISTOR 680K
Ω
1/10W
R658 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R659 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R660 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R661 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R662 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R663 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R665 BIRC6810025N00 C RESISTOR 680
Ω
1/2W
R666 BIRC6810025N00 C RESISTOR 680
Ω
1/2W
R669 BIRC1220105A00 C RESISTOR 1.2K
Ω
1/10W
R670 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R671 BIRC5620085M00 C RESISTOR 5.6K
Ω
1/8W J
R672 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R673 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R674 BIRC2210045M00 C RESISTOR 220
Ω
1/4W J C
R675 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R676 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R677 BIRC4740105A00 C RESISTOR 470K
Ω
1/10W
R678 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R679 BIRC4740105A00 C RESISTOR 470K
Ω
1/10W
R680 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R681 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R682 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R683 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R684 BIRC2730105A00 C RESISTOR 27K
Ω
1/10W
R685 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R686 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R687 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R688 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R689 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R690 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R691 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
Symbol No.
Part No. Part Name Description Local
R692 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R695 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
L601 BI2600702V CHOKE COIL 1uH
L602 BI2600702V CHOKE COIL 1uH
CN202 BI12S40047V CONNECTOR 4P
CN902 BI12S400551 CONNECTOR 4P
CN903 BI12S90025V CONNECTOR 9P
CW501 BI12S240004V FFC CONNECTOR 24P
JK601 BI2301271 SPK TERMINAL PST- 413-151
RF601 BIRF1000045M00 FUSE RESISTOR 0
Ω
1/4W
RF603 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
RF604 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
RY601 BI8RL00191V RELAY
DC12V ME-7C-012-
3H
Symbol No.
Part No. Part Name Description Local
XXXXX BI1205291Y FFC CABLE
16P for CD MECH to
MAIN CN701
XXXXX BI12P30249Y WIRE
3P for CASS MECH
to MAIN CN301
XXXXX BI12P80102Y WIRE
8P for CASS MECH
to MAIN CN302
XXXXX BI1206261Y FFC CABLE
18P for FRONT
CW201 to MAIN
CN201
XXXXX BI1206781Y FFC CABLE
9P for CASS MECH
to MAIN CN303
XXXXX BI1206321Y FFC CABLE
12P for TUNER to
MAIN CN306
XXXXX BI1206761Y FFC CABLE
24P for AMP CW501
to MAIN CN601
Symbol No.
Part No. Part Name Description Local
To Next Page
