1-2 (No.MB350)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier Output Power 180 W per channel, min. RMS, driven into 6 Ω at
1kHz, with no more than 10% total harmonic distortion
Input Sensitivity/Impedance (1 kHz) AUX IN:400 mV/50 kΩ
Speaker terminals 6 - 16 Ω
Phones 32 Ω - 1 kΩ
15 mW/ch output into 32 Ω
Cassette Deck Section Frequency Response : Type l (NORMAL) 63 Hz - 12 500 Hz
Wow And Flutter 0.15% (WRMS)
CD Player CD Capacity 3 CDs
Dynamic Range 85 dB
Signal-To-Noise Ratio 85 dB
Wow And Flutter Unmeasurable
Tuner FM Tuner 87.5 MHz - 108.0 MHz
AM Tuner 530 kHz - 1 710 kHz
Unit Dimensions 270 mm × 306 mm × 456 mm (W/H/D)
(10-11/16" × 12-1/16" × 18")
Mass Approx. 8.6 kg (19.0 lbs)
Speaker Specifications (each unit)
SP-MXKC4
Type 3-way bass-reflex type
Speaker Unit Woofer: 16 cm (6-5/16") cone × 1
Mid: 5cm (2") cone × 1
Tweeter: 2 cm (13/16") dome × 1
Power Handling Capacity 180 W
Impedance 6 Ω
Frequency Range 45 Hz - 22 000 Hz
Sound pressure level 87 dB/W·m
Dimensions 266 mm × 333 mm × 241 mm (W/H/D)
(10-1/2" × 13-1/8" × 9-1/2")
Mass Approx. 3.9 kg (8.6 lbs)
Power Specifications Power Requirements AC 120 V , 60 Hz
Power Consumption 150 W (power on mode)
22 W (in Standby mode)
