JVC MX-KC4 Service Manual

3-14
Front board
Block No. [0][2]
JR26 BIRC0000085A003 C RESISTOR 0 Ω 1/8W
JR28 BIRC0000165A005 C RESISTOR 0
Ω 1/16W
P1 BI11A050M0V WIRE 50mm
X1 BI2100942 CRYSTAL 75KHz
X801 BI2102361 CRYSTAL 16.9344MHz
XT301 BI2101012 CRYSTAL 32.768KHz
XT302 BI29ZTA8.00P015 C. RESONTOR 8MHz
XXXXX BI251407G01V MAIN PWB
 Symbol No. Part No. Part Name Description Local
IC201 RPM7138-V4 IC BI115291
IC202 S5G5128A |C BI116661
Q201 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q202 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q205 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
D201 1SS133 FR DIODE BI31SS133M0007
D202 1SS133 FR DIODE BI31SS133M0007
D206 1SS133 FR DIODE BI31SS133M0007
D207 1SS133 FR DIODE BI31SS133M0007
D208 1SS133 FR DIODE BI31SS133M0007
C201 BICC103500KA042 C CAPACITOR 0.01uF
C202 BICC103500KA042 C CAPACITOR 0.01uF
C203 BICE106500MP010 E CAPACITOR 10uF
C204 BICC102500KA042 C CAPACITOR 1000pF
C205 BICE226500MP010 E CAPACITOR 22uF
C207 BICE226500MP010 E CAPACITOR 22uF
C209 BICC104500KA042 C CAPACITOR 0.1uF
C210 BICC103500KA042 C CAPACITOR 0.01uF
C211 BICE107500MP015 E CAPACITOR 100uF
C212 BICC104500KA042 C CAPACITOR 0.1uF
C213 BICC104500KA042 C CAPACITOR 0.1uF
C220 BICC104500KA042 C CAPACITOR 0.1uF
C221 BICC102500KA042 C CAPACITOR 1000pF
C222 BICC102500KA042 C CAPACITOR 1000pF
C223 BICH223500KM019 C CAPACITOR 0.022uF
C224 BICC102500KA042 C CAPACITOR 1000pF
C225 BICC104500KA042 C CAPACITOR 0.1uF
C226 BICC104500KA042 C CAPACITOR 0.1uF
C227 BICC101500JA041 C CAPACITOR 100pF
C228 BICC101500JA041 C CAPACITOR 100pF
C229 BICC101500JA041 C CAPACITOR 100pF
C230 BICC102500KA042 C CAPACITOR 1000pF
C231 BICC102500KA042 C CAPACITOR 1000pF
R201 BIRC0000165A005 C RESISTOR 0
Ω 1/16W
R203 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R204 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R205 BIRC1010105A005 C RESISTOR 100
Ω 1/10W
R206 BIRC2210105A005 C RESISTOR 220
Ω 1/10W
R207 BIRC0100105A005 C RESISTOR 1
Ω 1/10W
R208 BIRC0100105A005 C RESISTOR 1
Ω 1/10W
R209 BIRC2200105A005 C RESISTOR 22
Ω 1/10W
R210 BIRC2730105A005 C RESISTOR 27K
Ω 1/10W
R212 BIRC1030085M000 C RESISTOR 10K
Ω 1/8W
R213 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R214 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R215 BIRC9110105A005 C RESISTOR 910
Ω 1/10W
R216 BIRC1120165A005 C RESISTOR 1.1K
Ω 1/10W
R217 BIRC1220105A005 C RESISTOR 1.2K
Ω 1/10W
R218 BIRC1820105A005 C RESISTOR 1.8K
Ω 1/10W
R219 BIRC2020105A005 C RESISTOR 2K
Ω 1/10W
R220 BIRC3020105A005 C RESISTOR 3K
Ω 1/10W
R221 BIRC3920105A005 C RESISTOR 3.9K
Ω 1/10W
R222 BIRC6220105A005 C RESISTOR 6.2K
Ω 1/10W
R223 BIRC9110105A005 C RESISTOR 910
Ω 1/10W
R224 BIRC1120165A005 C RESISTOR 1.1K
Ω 1/10W
R225 BIRC1220105A005 C RESISTOR 1.2K
Ω 1/10W
 Symbol No. Part No. Part Name Description Local
R226 BIRC1820105A005 C RESISTOR 1.8K Ω 1/10W
R227 BIRC2020105A005 C RESISTOR 2K
Ω 1/10W
R228 BIRC3020105A005 C RESISTOR 3K
Ω 1/10W
R229 BIRC3920105A005 C RESISTOR 3.9K
Ω 1/10W
R230 BIRC6220105A005 C RESISTOR 6.2K
Ω 1/10W
R231 BIRC9110105A005 C RESISTOR 910
Ω 1/10W
R232 BIRC1120165A005 C RESISTOR 1.1K
Ω 1/10W
R233 BIRC1220105A005 C RESISTOR 1.2K
Ω 1/10W
R234 BIRC1820105A005 C RESISTOR 1.8K
Ω 1/10W
R235 BIRC2020105A005 C RESISTOR 2K
Ω 1/10W
R236 BIRC3020105A005 C RESISTOR 3K
Ω 1/10W
R237 BIRC3920105A005 C RESISTOR 3.9K
Ω 1/10W
R238 BIRC6220105A005 C RESISTOR 6.2K
Ω 1/10W
R239 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R240 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R242 BIRC1000105A005 C RESISTOR 10
Ω 1/10W
R246 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R248 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R249 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R250 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R251 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R252 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R253 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R254 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R255 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R256 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R257 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R258 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R259 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R260 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R261 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R262 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R263 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R264 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R265 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R266 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R267 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R268 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R269 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R270 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R271 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R272 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R273 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R274 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R275 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R276 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R277 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R278 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R279 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R280 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R281 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R282 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R283 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R284 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R285 BIRC8200105A005 C RESISTOR 82
Ω 1/10W
R286 BIRC8200105A005 C RESISTOR 82
Ω 1/10W
R290 BIRC0000165A005 C RESISTOR 0
Ω 1/16W
R291 BIRC1010105A005 C RESISTOR 100
Ω 1/10W
R292 BIRC1010105A005 C RESISTOR 100
Ω 1/10W
R293 BIRC1010105A005 C RESISTOR 100
Ω 1/10W
VR201 BI804401 JOG SWITCH RE012307P
L201 BI26100000KM002 COIL 10UH
L202 BI26010000KM002 COIL 1uH
L203 BI18A843556N000 FILTER BEAD 843556
CW201 BI12S1800071 FFC CONNECTOR 18P H 1.25mm
CW202 BI12P402341 CONN. WIRE 4P
CW205 BI12P30232V WIRE 3P
FL201 BI2701941 VFD HNA-14MS09
JK201 BI2301481V EARPHONE JACK PJ-310H
JK202 BI2301471V AUX JACK PJ-310H-03
JR201 BIRC2020105A005 C RESISTOR 2K
Ω 1/10W
JR202 BIRC2020105A005 C RESISTOR 2K
Ω 1/10W
LD201 B4531E LED BI28B4531EP0110
LD202 SLR-342 LED BI28SLR342VP010
S201 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S202 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
 Symbol No. Part No. Part Name Description Local
