JVC MX-KC4 Service Manual

3-15
AMP. board
Block No. [0][3]
S203 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S204 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S205 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S206 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S207 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S208 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S209 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S210 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S211 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S212 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S213 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S214 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S215 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S216 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S217 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S218 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S219 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S220 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S221 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S222 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S223 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S224 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S225 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S226 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
S227 BI8SKRGAED0P015 TOUCH SWITCH SKRGAED010
XXXXX BI251292G01V FRONT PWB
XXXXX BI107481010101 LED HOLDER
XXXXX BI202552010101 VFD HOLDER (x2)
XXXXX BI202579010101 SENSOR HOLDER
XXXXX BI301923010101 RUBBER VFD (x2)
XXXXX BI1206341V FLAT CABLE 2P (x2)
XXXXX BI1206351V FLAT CABLE 8P
 Symbol No. Part No. Part Name Description Local
IC601 STK412-430 POWER I.C BI118201
Q601 2SC3052F TRANSISTOR BI2SC3052FA013H
Q603 DTA114YK DIGI TRANSISTOR BI2DTA114YKA011
Q604 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q605 2SC3052F TRANSISTOR BI2SC3052FA013H
Q606 DTC114EK DIGI TRANSISTOR BI2DTC114EKA011
Q607 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q608 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q609 2SC3052F TRANSISTOR BI2SC3052FA013H
Q610 2SC3052F TRANSISTOR BI2SC3052FA013H
Q611 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q612 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q613 KTA1267G TRANSISTOR BI2KTA1267GP000
Q614 KTA1267G TRANSISTOR BI2KTA1267GP000
Q615 2SC3052F TRANSISTOR BI2SC3052FA013H
Q616 2SC3052F TRANSISTOR BI2SC3052FA013H
Q617 2SC3052F TRANSISTOR BI2SC3052FA013H
Q618 2SC3052F TRANSISTOR BI2SC3052FA013H
Q619 DTC114YK DIGI TRANSISTOR BI2DTC114YKA011
Q620 DTA114YK DIGI TRANSISTOR BI2DTA114YKA011
Q621 DTA114YK DIGI TRANSISTOR BI2DTA114YKA011
Q622 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q623 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q624 DTC114YK DIGI TRANSISTOR BI2DTC114YKA011
Q625 DTC114YK DIGI TRANSISTOR BI2DTC114YKA011
Q626 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
D601 1N4003 DIODE BI31N4003SEN000
D602 1N4003 DIODE BI31N4003SEN000
D603 1N4003 DIODE BI31N4003SEN000
D605 1N4003 DIODE BI31N4003SEN000
D606 1N4003 DIODE BI31N4003SEN000
D607 UZ12BSC Z DIODE BI3UZ12BSCM0000
D609 UZ30BSD Z DIODE BI3UZ30BSDM0000
D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
 Symbol No. Part No. Part Name Description Local
D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
D613 1N4003 DIODE BI31N4003SEN000
D614 RS402M B RECTIFIER BI3RS402M1
D615 G5SBA60 DIODE BI3G5SBA601
D616 UZ15BSC Z DIODE BI3UZ15BSCM0000
D617 UZ15BSC Z DIODE BI3UZ15BSCM0000
D618 1SS133 FR DIODE BI31SS133M0007
D619 1SS133 FR DIODE BI31SS133M0007
D620 1SS133 FR DIODE BI31SS133M0007
D621 1SS133 FR DIODE BI31SS133M0007
D622 1SS133 FR DIODE BI31SS133M0007
D623 1SS133 FR DIODE BI31SS133M0007
D624 1SS133 FR DIODE BI31SS133M0007
D625 1SS133 FR DIODE BI31SS133M0007
D626 1SS133 FR DIODE BI31SS133M0007
D627 1SS133 FR DIODE BI31SS133M0007
D630 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
C601 BICC104250ZA043 C CAPACITOR 0.1uF
C602 BICC104250ZA043 C CAPACITOR 0.1uF
C603 BICC104250ZA043 C CAPACITOR 0.1uF
C604 BICC104250ZA043 C CAPACITOR 0.1uF
C605 BICE47825M61 E CAPACITOR 4700uF 25V
C606 BICE105500MP015 E CAPACITOR 1uF 50V
C607 BICE107250MP015 E CAPACITOR 100uF 25V
C608 BICC104250ZA043 C CAPACITOR 0.1uF
C609 BICE107160MP015 E CAPACITOR 100uF 16V
C610 BICE476630MP015 E CAPACITOR 47uF 63V
C611 BICE226500MP015 E CAPACITOR 22uF 50V
C612 BICC103500KA042 C CAPACITOR 0.01uF
C613 BICE226500MP015 E CAPACITOR 22uF 50V
C614 BICE106250MP015 E CAPACITOR 10uF 25V
C615 BICC103500KA042 C CAPACITOR 0.01uF
C616 BICE477100MP015 E CAPACITOR 470uF 10V
C617 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C618 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C619 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C620 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C621 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C622 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C623 BICE47835M61 E CAPACITOR 4700uF 35V
C624 BICE47835M61 E CAPACITOR 4700uF 35V
C625 BICE33871M2V E CAPACITOR 3300uF 71V
C626 BICE33871M2V E CAPACITOR 3300uF 71V
C627 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C628 BICM682101KP015 P CAPACITOR 0.0068uF 100V
C629 BICM562101JP015 P CAPACITOR 0.0056uF 100V
C630 BICM562101JP015 P CAPACITOR 0.0056uF 100V
C631 BICE107101MP015 E CAPACITOR 100uF 100V
C632 BICE107101MP015 E CAPACITOR 100uF 100V
C633 BICC471500JA041 C CAPACITOR 470pF
C634 BICC471500JA041 C CAPACITOR 470pF
C635 BICE107100MP015 E CAPACITOR 100uF 10V
C636 BICE107100MP015 E CAPACITOR 100uF 10V
C637 BICC120500JA041 C CAPACITOR 12pF
C638 BICC120500JA041 C CAPACITOR 12pF
C639 BICC472500KA042 C CAPACITOR 4700pF
C640 BICC472500KA042 C CAPACITOR 4700pF
C641 BICE475500MP015 E CAPACITOR 4.7uF 50V
C642 BICE475500MP015 E CAPACITOR 4.7uF 50V
C643 BICE475500MP015 E CAPACITOR 4.7uF 50V
C644 BICE105500MP015 E CAPACITOR 1uF 50V
C645 BICM104101KP015 P CAPACITOR 0.1uF 100V
C646 BICM104101KP015 P CAPACITOR 0.1uF 100V
C647 BICM104101KP015 P CAPACITOR 0.1uF 100V
C648 BICM104101KP015 P CAPACITOR 0.1uF 100V
C649 BICC121500JA041 C CAPACITOR 120pF
C650 BICE476160MP015 E CAPACITOR 47uF 16V
C651 BICC223500KA042 C CAPACITOR 0.022uF
C652 BICE226500MP015 E CAPACITOR 22uF 50V
C653 BICE227100MP015 E CAPACITOR 220uF 10V
C654 BICE106250MP015 E CAPACITOR 10uF 25V
C655 BICC153500KA042 C CAPACITOR 0.015uF
C656 BICC153500KA042 C CAPACITOR 0.015uF
C657 BICE475500MP015 E CAPACITOR 4.7uF 50V
R262 BIRC4720105A005 C RESISTOR 4.7K
Ω 1/10W
R600 BIRC8210105A005 C RESISTOR 820
Ω 1/10W
 Symbol No. Part No. Part Name Description Local
