JVC MX-KC4 Service Manual

3-16
Power trans. board
Block No. [0][4]
Wiring
Block No. [0][5]
R601 BIRC4720105A005 C RESISTOR 4.7K Ω 1/10W
R602 BIRC7500105A005 C RESISTOR 75
Ω 1/10W
R605 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R606 BIRC3320105A005 C RESISTOR 3.3K
Ω 1/10W
R607 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R608 BIRC1010085N000 C RESISTOR 100
Ω 1/8W
R609 BIRC1010085N000 C RESISTOR 100
Ω 1/8W
R610 BIRC1540105A005 C RESISTOR 150K
Ω 1/10W
R611 BIRC5630105A005 C RESISTOR 56K
Ω 1/10W
R612 BIRC4720105A005 C RESISTOR 4.7K
Ω 1/10W
R613 BIRF1010025N000 FUSE RESISTOR 100
Ω 1/2W
R614 BIRF1010025N000 FUSE RESISTOR 100
Ω 1/2W
R615 BIRM1020N25N000 M RESISTOR 1K
Ω 2W
R616 BIRM1020N25N000 M RESISTOR 1K
Ω 2W
R617 BIRC5610105A005 C RESISTOR 560
Ω 1/10W
R618 BIRC0000105A005 C RESISTOR 0
Ω 1/16W
R620 BIRC3330105A005 C RESISTOR 33K
Ω 1/10W
R621 BIRC5610105A005 C RESISTOR 560
Ω 1/10W
R622 BIRC0000105A005 C RESISTOR 0
Ω 1/16W
R624 BIRC2720105A005 C RESISTOR 2.7K
Ω 1/10W
R625 BIRC2720105A005 C RESISTOR 2.7K
Ω 1/10W
R627 BIRC4720105A005 C RESISTOR 4.7K
Ω 1/10W
R628 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R629 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R630 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R631 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R632 BIRM001530V M RESISTOR 0.15
Ω 3W
R633 BIRM001530V M RESISTOR 0.15
Ω 3W
R634 BIRM001530V M RESISTOR 0.15
Ω 3W
R635 BIRM001530V M RESISTOR 0.15
Ω 3W
R636 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R637 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R638 BIRC1530105A005 C RESISTOR 15K
Ω 1/10W
R639 BIRC1530105A005 C RESISTOR 15K
Ω 1/10W
R640 BIRF1010025N000 FUSE RESISTOR 100
Ω 1/2W
R641 BIRF1010025N000 FUSE RESISTOR 100
Ω 1/2W
R642 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R643 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R644 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R645 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R646 BIRC4710105A005 C RESISTOR 470
Ω 1/10W
R647 BIRC4740105A005 C RESISTOR 470K
Ω 1/10W
R648 BIRC0470045N000 C RESISTOR 4.7
Ω 1/4W
R649 BIRC0470045N000 C RESISTOR 4.7
Ω 1/4W
R650 BIRC1040105A005 C RESISTOR 100K
Ω 1/10W
R651 BIRC1040105A005 C RESISTOR 100K
Ω 1/10W
R652 BIRC1040105A005 C RESISTOR 100K
Ω 1/10W
R653 BIRC1000085M000 C RESISTOR 10
Ω 1/8W
R654 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R655 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R656 BIRC1500085M000 C RESISTOR 15
Ω 1/8W
R657 BIRC6840105A005 C RESISTOR 680K
Ω 1/10W
R658 BIRC4730105A005 C RESISTOR 47K
Ω 1/10W
R659 BIRC2220105A005 C RESISTOR 2.2K
Ω 1/10W
R660 BIRC3920105A005 C RESISTOR 3.9K
Ω 1/10W
R661 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R662 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R663 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R664 BIRC1020105A005 C RESISTOR 1K
Ω 1/10W
R665 BIRM1020N25N000 M RESISTOR 1K
Ω 2W
R666 BIRM1020N25N000 M RESISTOR 1K
Ω 2W
R667 BIRC1030105A005 C RESISTOR 10K
Ω 1/10W
R668 BIRC1020085M000 C RESISTOR 1K
Ω 1/8W
R669 BIRC1220105A005 C RESISTOR 1.2K
Ω 1/10W
R671 BIRC5620085M000 C RESISTOR 5.6K
Ω 1/8W
R672 BIRC3300045M000 C RESISTOR 33
Ω
L601 BI2601141 COIL 3.0uH
L602 BI2601141 COIL 3.0uH
CN202 BI12S40047V CONNECTOR 4P V 2.5mm
CN602 BI12S200161V CONNECTOR 4P V 2mm
CN903 BI12S90025V CONNECTOR 9P H 2.5mm
CW601 BI12S220006V FFC CONNECTOR 22P H 1.25mm
JK601 BI2301271 TERMINAL SP PST- 413-151
JR601 BIRC0000105A005 C RESISTOR 0
Ω 1/16W
 RF601 BIRF3300025N000 FUSE RESISTOR 33 Ω 1/2W
RY601 BI8RL00191 RELAY 12V
 Symbol No. Part No. Part Name Description Local
XXXXX BI640MXKB4H0500 AMP PWB
XXXXX BI202555010101 HEAT SINK transistor
XXXXX BI12P20205V WIRE 2P L=60mm
XXXXX BIRT103THMSP015 THMS RESISTOR 10K
Ω
 Symbol No. Part No. Part Name Description Local
 C951 BICT224275M CAPACITOR 0.22uF 275V
CW902 BI12P90062V WIRE P=2.5mm L=140mm
XXXXX BI201196010101 FUSE HOLDER CX-NV300
XXXXX BI201323010101 TERMINAL 1P
XXXXX BI251289G01V PWR TRANS PWB
 Symbol No. Part No. Part Name Description Local
CN201 BI1206261V FF CABLE 18P
CN401 BI12P30215V WIRE 3P
CN402 BI12P80102V WIRE 8P
CN403 BI1206271V FF CABLE 11P
CN601 BI1206251V FF CABLE 22P
CN701 BI1205291U FF CABLE 16P
XXXXX BI300723010102 MOUNTING LUG PG CW-2
 Symbol No. Part No. Part Name Description Local
