JVC MX-KC4 Service Manual

3-9
Electrical parts list
Main board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC1 LA1823 IC BI113251
IC4 LC72136N IC BI113271
IC301 S3C825AC39 IC BI118731
IC302 BU4051BCF IC BI116691
IC401 HA12237 IC BI115011
IC501 TDA7440D IC BI113231
IC502 JCV8011 IC BI116561
IC503 BA4558F IC BI103952
IC701 S1L9226 IC BI116431
IC702 BA5927S IC BI118221
IC801 BH18FB1WG IC BI118171
IC802 NJM7808FA IC BI110061
IC803 SDRAM-16M IC BI116461
IC804 S5L9279 IC BI116401
Q1 KTC3194 TRANSISTOR BI2KTC3194P000V
Q2 KTC3195Y TRANSISTOR BI2KTC3195YP000
Q3 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q4 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q5 DTA114YK DIGI TRANSISTOR BI2DTA114YKA011
Q7 2SC3052 TRANSISTOR BI2SC3052FA013H
Q8 KTA1267G TRANSISTOR BI2KTA1267GP000
Q302 2SC3052 TRANSISTOR BI2SC3052FA013H
Q303 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q304 2SC1815 TRANSISTOR BI2SC1815GRP000
Q401 2SC3052 TRANSISTOR BI2SC3052FA013H
Q402 2SC3052 TRANSISTOR BI2SC3052FA013H
Q403 2SC3052 TRANSISTOR BI2SC3052FA013H
Q404 2SC3052 TRANSISTOR BI2SC3052FA013H
Q405 DTA114YK DIGI TRANSISTOR BI2DTA114YKA011
Q406 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q407 KTA1267G TRANSISTOR BI2KTA1267GP000
Q408 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q409 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q410 KTA1267G TRANSISTOR BI2KTA1267GP000
Q411 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q412 KTC3203Y TRANSISTOR BI2KTC3203YP000
Q413 KTC3200G TRANSISTOR BI2KTC3200GP000
Q414 2SC3052 TRANSISTOR BI2SC3052FA013H
Q415 KRA1273Y TRANSISTOR BI2KTA1273YP000
Q416 2SC3052 TRANSISTOR BI2SC3052FA013H
Q417 KRA1273Y TRANSISTOR BI2KTA1273YP000
Q418 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q419 KRA1273Y TRANSISTOR BI2KTA1273YP000
Q420 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q501 2SC3052 TRANSISTOR BI2SC3052FA013H
Q502 2SC3052 TRANSISTOR BI2SC3052FA013H
Q503 2SC3052 TRANSISTOR BI2SC3052FA013H
Q504 KTA1267G TRANSISTOR BI2KTA1267GP000
Q505 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q506 KTA1267G TRANSISTOR BI2KTA1267GP000
Q507 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q508 2SC1815 TRANSISTOR BI2SC1815GRP000
Q509 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q510 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q701 KRA1266G TRANSISTOR BI2KTA1266GP000
Q703 KTC3205 TRANSISTOR BI2KTC3205P0008
Q704 2SC1815 TRANSISTOR BI2SC1815GRP000
D1 1SS133 FR DIODE BI31SS133M0007
D2 1SS133 FR DIODE BI31SS133M0007
D3 1SS133 FR DIODE BI31SS133M0007
D4 1SS133 FR DIODE BI31SS133M0007
D5 1SS133 FR DIODE BI31SS133M0007
D6 1SS133 FR DIODE BI31SS133M0007
D7 SVC203 VARACTOR DIODE BI3SVC203CPA000
D8 SVC203 VARACTOR DIODE BI3SVC203CPA000
D9 1SS133 FR DIODE BI31SS133M0007
D10 1SS133 FR DIODE BI31SS133M0007
D11 1SS133 FR DIODE BI31SS133M0007
D12 1SS133 FR DIODE BI31SS133M0007
D13 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D14 1SS133 FR DIODE BI31SS133M0007
D15 1SS133 FR DIODE BI31SS133M0007
D301 1SS133 FR DIODE BI31SS133M0007
D302 1SS133 FR DIODE BI31SS133M0007
D303 1SS133 FR DIODE BI31SS133M0007
D304 1SS133 FR DIODE BI31SS133M0007
D305 1SS133 FR DIODE BI31SS133M0007
D306 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
D307 1SS133 FR DIODE BI31SS133M0007
D308 1SS133 FR DIODE BI31SS133M0007
D309 1SS133 FR DIODE BI31SS133M0007
D401 1SS133 FR DIODE BI31SS133M0007
D402 1SS133 FR DIODE BI31SS133M0007
D403 1SS133 FR DIODE BI31SS133M0007
D404 1SS133 FR DIODE BI31SS133M0007
D501 1SS133 FR DIODE BI31SS133M0007
D502 1N4001 DIODE BI31N4001M0006
D503 1SS133 FR DIODE BI31SS133M0007
D504 1SS133 FR DIODE BI31SS133M0007
D505 1SS133 FR DIODE BI31SS133N0007
D506 1SS133 FR DIODE BI31SS133M0007
D507 UZ11BSC Z DIODE BI3UZ11BSCM0000
D508 1SS133 FR DIODE BI31SS133M0007
D509 1SS133 FR DIODE BI31SS133M0007
D510 1SS133 FR DIODE BI31SS133M0007
D710 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D711 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D712 1SS133 FR DIODE BI31SS133M0007
C1 BICC223500KA042 C CAPACITOR 0.022uF
C2 BICC080500DA041 C CAPACITOR 8pF
C3 BICC102500KA042 C CAPACITOR 1000pF
C4 BICC223500KA042 C CAPACITOR 0.022uF
C5 BICC473500KA042 C CAPACITOR 0.047uF
C6 BICC100500DA041 C CAPACITOR 10pF
C7 BICC120500JA041 C CAPACITOR 12pF
C8 BICC80500DA041V C CAPACITOR 8pF
C9 BICC473500KA042 C CAPACITOR 0.047uF
C10 BICC103500KA042 C CAPACITOR 0.01uF
C11 BICC473500KA042 C CAPACITOR 0.047uF
C12 BICC103500KA042 C CAPACITOR 0.01uF
C13 BICE107100MP015 E CAPACITOR 100uF 10V
C14 BICC223500KA042 C CAPACITOR 0.022uF
C15 BICC223500KA042 C CAPACITOR 0.022uF
C16 BICE106250MP015 E CAPACITOR 10uF 25V
C17 BICC047500CA041 C CAPACITOR 4.7pF
C18 BICC103500KA042 C CAPACITOR 0.01uF
C19 BICC103500KA042 C CAPACITOR 0.01uF
C20 BICC103500KA042 C CAPACITOR 0.01uF
C21 BICC220500JA041 C CAPACITOR 22pF
C22 BICC102500KA042 C CAPACITOR 1000pF
C23 BICC103500KA042 C CAPACITOR 0.01uF
C24 BICC102500KA042 C CAPACITOR 1000pF
C25 BICE475500MP015 E CAPACITOR 4.7uF 50V
C27 BICC222500KA042 C CAPACITOR 2200pF
C28 BICM474500JP015 P CAPACITOR 0.47uF
C29 BICE224500MP015 E CAPACITOR 0.22uF 50V
C30 BICE335500MP015 E CAPACITOR 3.3uF 50V
C31 BICC103500KA042 C CAPACITOR 0.01uF
C32 BICC060500CA041 C CAPACITOR 6pF
C33 BICE226250MP015 E CAPACITOR 22uF 25V
C34 BICC223500KA042 C CAPACITOR 0.022uF
C36 BICC183500KA042 C CAPACITOR 0.018uF
C37 BICC183500KA042 C CAPACITOR 0.018uF
C38 BICC102500KA042 C CAPACITOR 1000pF
C39 BICC102500KA042 C CAPACITOR 1000pF
C40 BICE225500MP015 E CAPACITOR 2.2uF 50V
C41 BICE225500MP015 E CAPACITOR 2.2uF 50V
C42 BICC471500JA041 C CAPACITOR 470pF
C43 BICC471500JA041 C CAPACITOR 470pF
C44 BICC100500DA041 C CAPACITOR 10pF
C50 BICE476160MP015 E CAPACITOR 47uF 16V
C51 BICC120500JA041 C CAPACITOR 12pF
C52 BICC120500JA041 C CAPACITOR 12pF
C53 BICM105500JP015 P CAPACITOR 1uF
C54 BICC392500KA042 C CAPACITOR 3900pF
 Symbol No. Part No. Part Name Description Local
