1-2 (No.MB664<Rev.002>)
SPECIFICATION
MX-KC68J/C/MX-KC38J/C
Specifications and appearance are subject to change without prior notice.
Amplifier section OUTPUT POWER
Main speakers 110 W per channel min. RMS driven into 3Ω at 1 kHz with no more than 10% total harmonic distortion
Speakers/Impedance 3Ω - 6 Ω
Subwoofer (for MX-KC68) 180 W per channel min. RMS driven into 8 Ω at 63 Hz with no more than 10% total harmonic distortion
Speakers/Impedance 8 Ω - 16 Ω
Tuner section
FM tuning range 87.5 MHz - 108.0 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player section
Dynamic range 90 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
Main speakers (MX-KC68/SP-MXKC38)
Type 3-Way 3-Speaker Bass-Reflex Type
Speaker units Main Woofer 16 cm (6-5/16 inches) cone x 1
Mid Range 5 cm (2 inches) cone x 1
Tweeter 2 cm (13/16 inches) dome x 1
Power Handling Capacity 110 W
Impedance 3 Ω
Frequency Range 41 Hz - 35 kHz
Sound Pressure Level 83 dB/W•m
Dimensions (approx.) 210 mm x 315 mm x 220 mm (W/H/D)
(8-5/16 inches x 12-7/16 inches x 8-11/16 inches)
Mass (approx.) 3.0 kg (6.7 lbs) each
Subwoofer (MX-KC68)
Type 1-Way Bass-Reflex Type
Speaker 16 cm (6-5/16 inches) cone x 1
Power Handling Capacity 180 W
Impedance 8 Ω
Frequency Range 38 Hz - 5 kHz
Sound Pressure Level 83 dB/W•m
Dimensions (approx.) 210 mm x 315 mm x 242 mm (W/H/D)
(8-5/16 inches x 12-7/16 inches x 9-9/16 inches)
Mass (approx.) 3.4 kg (7.5 lbs)
General
Power requirements AC 120 V , 60 Hz
Audio input AUDIO IN 400 mV/47 kΩ
Power supply to iPod DC 5 V 500 mA
Power consumption 95 W (MX-KC68) - power on
60 W (MX-KC38) - power on
9 W - standby mode, without charging iPod
0.9 W or less - save mode
Dimensions (W x H x D) 215 mm x 307 mm x 309 mm
(8-1/2 inches x 12-1/8 inches x 12-3/16 inches)
Mass (approx.) 3.8 kg (8.4 lbs) (MX-KC68)
3.6 kg (8.0 lbs) (MX-KC38)
