(No.MB664<Rev.002>)1-3
MX-KC68B/E/EN/EV
Specifications and appearance are subject to change without prior notice.
Amplifier section
OUTPUT POWER Main speakers
110 W per channel min. RMS driven into 3
Ω
at 1 kHz with no more than 10% total harmonic distortion
Speakers/Impedance: 3 Ω - 6 Ω
Subwoofer
180 W min. RMS driven into 8
Ω
at 63 Hz with no more than 10% total harmonic distortion
Speakers/Impedance: 8 Ω - 16 Ω
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 522 kHz - 1 629 kHz
CD player section Dynamic range 86 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
Speakers
Main speakers
(SP-MXKC68F)
Type 3-Way 3-Speaker Bass-Reflex Type
Speaker units Main Woofer 16 cm cone x 1
Mid Range 5 cm cone x 1
Tweeter 2 cm dome x 1
Power Handling Capacity 110 W
Impedance 3 Ω
Frequency Range 41 Hz - 35 kHz
Sound Pressure Level 83 dB/W
•m
Dimensions (approx.) 210 mm x 315 mm x 220 mm (W/H/D)
Mass (approx.) 3.0 kg each
Subwoofer
(SP-MXKC68W)
Type 1-Way Bass-Reflex Type
Speaker 16 cm cone x 1
Power Handling Capacity 180 W
Impedance 8 Ω
Frequency Range 38 Hz - 5 kHz
Sound Pressure Level 83 dB/W
•m
Dimensions (approx.) 210 mm x 315 mm x 242 mm (W/H/D)
Mass (approx.) 3.4 kg
General
Power requirements AC 230 V , 50 Hz
Audio input AUDIO IN 400 mV/47 kΩ
Power supply to iPod DC 5 V 500 mA
Power consumption 95 W - power on
9 W - standby mode, without charging iPod
0.8 W or less - save mode
Dimensions (W x H x D) 215 mm x 307 mm x 309 mm
Mass (approx.) 3.8 kg
