G-2
CAUTION — Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, locate the apparatus as follows:
Top/Front/Back/Sides: No obstructions should be placed in the areas shown by the dimensions below.
Bottom: Place on the level surface. Maintain adequate air path for ventilation by placing on
a stand with a height of 10 cm or more.
In addition, maintain the best possible air circulation.
Front view of the main unit and speakers (CA-NXF40/CA-NXF30 and SP-NXF40F/SP-NXF30F)
Speaker SpeakerMain unit
Speaker Main unit
Front view of the main unit and speakers (CA-NXF55 and SP-THFT3F)
Speaker
Main unit
Side view of the main unit (CA-NXF55/CA-NXF40/CA-NXF30)
CAUTION
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
NX-F40_NX-F30[B].book Page 2 Thursday, December 24, 2009 2:00 PM
