– 74 –
Specifications
Amplifier
Output Power (IEC 268-3/DIN):
15 W per channel, min. RMS, both channels driven into
4 Ω at 1 kHz, with no more than 0.9% total harmonic
distortion
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
LINE IN : 260 mV/56 kΩ (at “LEVEL 1”)
640 mV/56 kΩ (at “LEVEL 2”)
Digital input:
OPTICAL DIGITAL IN : Optical
Signal wave length: 660 nm
Input level: –23 dBm to –15 dBm
(With the built-in sampling rate
converter, corresponding to 32 kHz/
44.1 kHz/48 kHz)
USB AUDIO : Revision 1.0, Full-speed (with
sampling frequency
—32 kHz, 44.1 kHz, 48 kHz)
Audio output level/Impedance (at 1 kHz)
LINE OUT : 215 mV/3.9 kΩ
Speakers/Impedance: 4 Ω – 16 Ω
Tuner
FM tuning range : 87.50 MHz — 108.00 MHz
AM (MW/LW) tuning range:
MW : 522 kHz — 1 629 kHz
LW : 144 kHz — 288 kHz
CD player
CD Capacity: 1 CD
Dynamic range: 88 dB
Signal-to-noise ratio: 95 dB
Wow and flutter: Immeasurable
MD recorder
Audio playing system: MiniDisc digital audio system
Recording system: Magneto-optical overwrite system
Reading system: Non-contact, semiconductor laser
pickup (λ=780 nm)
Error correction system:
CIRC (Cross Interleave Reed-
Solomon Code)
Sampling frequency: 44.1 kHz
(With sampling rate converter for
recording—32 kHz/44.1 kHz/
48 kHz)
Audio compression system:
ATRAC (Adaptive TRansform Acoustic
Coding)/ATRAC3 ( )
General
Power requirement: AC 230V , 50 Hz
Power consumption: 60 W (at operation)
1.1 W (on standby: with display
off)
1.3 W (on standby: with display on)
Dimensions (approx.):
150 mm x 237 mm x 274 mm (W/H/D)
Mass (approx.): 4.9 kg
Supplied accessories
See page 6.
Design and specifications are subject to change without
notice.
US and foreign patents licensed from Dolby Laboratories.
