JVC RC-BZ5RD

RC-BZ6BU
3-20
Item
Parts number Parts name Area
Remarks
A
C 613 GJ264143312101 C.CAPACITOR AXIAL 50V B K 3
C 614 GJ282031042415 M.CAPACITOR 50V J 0.1UF
C 615 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 616 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 617 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 618 GJ264262222101 A.CAPACITOR 16V X M 0.0022U
C 619 GJ264142712101 A.CAPACITOR AXIAL 50V B K 2
C 620 GJ264141812101 C.CAPACITOR 50V B K 180PF
C 622 GJ270114760332 E.CAPACITOR 10V M 47UF
C 623 GJ282031042415 M.CAPACITOR 50V J 0.1UF
C 628 GJ262104732402 C.CAPACITOR 25V YR K 0.047U
C 629 GJ270111070332 E.CAPACITOR 10V M VX 100UF
C 631 GJ270114770332 E.CAPACITOR 10V M 470UF
C 632 GJ270111070332 E.CAPACITOR 10V M VX 100UF
C 640 GJ264278222101 C.CAPACITOR 16V X M 0.0082U
C 641 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 651 GJ264032202101 C.CAPACITOR 50V SL J 22PF
C 652 GJ264032202101 C.CAPACITOR 50V SL J 22PF
C 653 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 655 GJ262104732402 C.CAPACITOR 25V YR K 0.047U
C 661 GJ264144712101 C.CAPACITOR 50V B K 470PF
C 662 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 663 GJ282032232415 M.CAPACITOR 50V J 0.022UF
C 664 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 665 GJ282031042415 M.CAPACITOR 50V J 0.1UF
C 671 GJ264262222101 A.CAPACITOR 16V X M 0.0022U
C 672 GJ264262222101 A.CAPACITOR 16V X M 0.0022U
C 673 GJ270112270332 E.CAPACITOR 10V M 220UF
C 674 GJ264182232101 C.CAPACITOR 25V F Z 0.022UF
C 675 GJ264141022101 C.CAPACITOR 50V B K 1000PF
C 676 GJ264141022101 C.CAPACITOR 50V B K 1000PF
C 690 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 691 GJ264141512101 C.CAPACITOR 50V B K 150PF
C 692 GJ264141512101 C.CAPACITOR 50V B K 150PF
C 693 GJ264141512101 C.CAPACITOR 50V B K 150PF
C 694 GJ264141512101 C.CAPACITOR 50V B K 150PF
C 695 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 696 GJ264141012101 C.CAPACITOR 50V B K 100PF
C 697 GJ264141012101 C.CAPACITOR 50V B K 100PF
C 698 GJ264141012101 C.CAPACITOR 50V B K 100PF
C 699 GJ264141012101 C.CAPACITOR 50V B K 100PF
C 709 GJ270102280132 E.CAPACITOR 6.3V M 2200UF
C 901 GJ262772232412 C.CAPACITOR 50V F Z 0.022UF
C 902 GJ262772232412 C.CAPACITOR 50V F Z 0.022UF
C 903 GJ262772232412 C.CAPACITOR 50V F Z 0.022UF
C 904 GJ262772232412 C.CAPACITOR 50V F Z 0.022UF
C 905 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 906 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 908 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 909 GJ270194750332 E.CAPACITOR 50V M 4.7UF
C 910 GJ270112270332 E.CAPACITOR 10V M 220UF
C 911 GJ270122260332 E.CAPACITOR 16V M 22UF
C 912 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 913 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF
C 914 GJ270112270332 E.CAPACITOR 10V M 220UF
C 915 GJ270111070332 E.CAPACITOR 10V M VX 100UF
C 916 GJ270114760332 E.CAPACITOR 10V M 47UF
CF 1 QAX0403-001 C FILTER FM 10.7M
CF 3 QAX0538-001Z CRYSTAL FM CDA10.7
CN301 GJ156450711 CONNECTOR 4PINS ST
CN303 QGF1212C1-13 FFC CONNECTOR 13PIN
CN304 QGF1212C1-17 FFC CONNECTOR 17PINS
CN306 TID-X03P-MI CONNECTOR 3 PINS RA WHIT
CN307 5268-03A CONNECTOR 3PINS RA
CN308 GJ156450911 CONNECTOR 6PINS ST
CN309 GJ158016511 TRANSISTOR 4PINS ST
CN310 QGA2501C3-03Z CONNECTOR IM GJ156450611
CN601 QGF1025C1-15 21-41 CONNECTOR 15PIN
D 1 SVC203SPA-JV-T VARI CAP VARIABLE FM CAP
D 2 SVC203SPA-JV-T VARI CAP VARIABLE FM CAP
D 5 1SS133Y DIODE GJ871999133
D 6 1SS133Y DIODE GJ871999133
D 8 KV1555N-T VARI CAPACITOR VARIABLE AM CAP
D 12 IN4001 DIODE RECT 1N4001 BUL
D 301 1SS133Y DIODE GJ871999133
D 303 1SS133Y DIODE GJ871999133
D 304 1SS133Y DIODE GJ871999133
D 305 1SS133Y DIODE GJ871999133
D 307 1SS133Y DIODE GJ871999133
D 661 1SS133Y DIODE GJ871999133
D 901 1N5401-M SI DIODE
A
GJ871903152
D 902 1N5401-M SI DIODE
A
GJ871903152
D 903 1N5401-M SI DIODE
A
GJ871903152
D 904 1N5401-M SI DIODE
A
GJ871903152
D 905 1SS133Y DIODE GJ871999133
D 906 1SS133Y DIODE GJ871999133
D 907 1SS133Y DIODE GJ871999133
D 908 1SS133Y DIODE GJ871999133
D 909 1SS133Y DIODE GJ871999133
D 910 1SS133Y DIODE GJ871999133
D 911 1SS133Y DIODE GJ871999133
D 912 IN4001 DIODE RECT 1N4001 BUL
D 914 1SS133Y DIODE GJ871999133
D 915 1SS133Y DIODE GJ871999133
D 917 1SS133Y DIODE GJ871999133
D 918 1SS133Y DIODE GJ871999133
D 995 1SS133Y DIODE GJ871999133
FC902 QNG0003-001Z FUSE CLIP GJ153321741
FC903 QNG0003-001Z FUSE CLIP GJ153321741
FC905 QNG0003-001Z FUSE CLIP GJ153321741
FC906 QNG0003-001Z FUSE CLIP GJ153321741
FW 1 GJ353170240107 CARD WIRE CN304 TO CN701
FW 2 VWF1015-08TTA CARD WIRE CN304 TO CD
FW 3 GJ353130150107 CARD WIRE CN303 TO CN703
IC 1 TA2104AN IC DIP 24 IF&MPX
IC 2 LC72136N IC PLL IC
IC301 TA2068N IC GJ313020121101
IC302 LA4597K IC
A
DIP POWER AMP
IC303 M62420SP-700 IC GJ313060301112
IC304 BA15218N IC GJ313010021103
IC601 AN8806SB IC RF AMP
IC602 BA6897FP IC POWER DRIVER
IC603 MN35510 IC 1 CHIP PROCISSE
J 9 QNC0043-001 AC SOCKET
A
125V 7A
J 301 GJ342010200113 JACK, H/P MSJ2000
(
BL
K 1 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 601 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 602 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
L 1 VQF1B20-019 OSC COIL FM OSC
L 2 VQC1505-002L RF COIL FM RF
L 3 VQB008M-506 BAR ANTENA GJV
Q
B008M506
L 4 QQR0723-001 OSC COIL AM OSC 7.5MM RE
L 7 VQP0018-221 INDUCTOR 220UH 10%
Q
40
L 10 QQL231K-4R7Y INDUCTOR 4.7UH
L 12 V03047-16 RF COIL SPRING CW
L 601 3A839N INDUCTOR 10UH RADIAL LEA
Electrical parts list ( Main board )
Block No. 01
Item
Parts number Parts name Area
Remarks
A
