RC-BZ6BU

3-19

Item

Parts number Parts name Area

Electrical parts list ( Main board )

Remarks

Block No. 01

C 3 GJ264130392101 C.CAPACITOR 50V SL K 3.9PF

C 6 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

C 7 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 9 GJ264031202101 A.CAPACITOR 50V SL J 12PF

C 13 GJ262102232402 C.CAPACITOR 25V YR K 0.022U

C 16 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

C 21 GJ262104732402 C.CAPACITOR 25V YR K 0.047U

C 22 GJ285214312415 M.CAPACITOR PP 100V J 430PF

C 23 GJ264081202101 C.CAPACITOR 50V CH J 12PF

C 31 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 32 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

C 33 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 35 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 36 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 37 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 38 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

C 40 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

C 41 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 42 GJ262104732402 C.CAPACITOR 25V YR K 0.047U

C 43 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 44 GJ270191050332 E.CAPACITOR 50V M 1UF

C 45 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 47 GJ262101532402 C.CAPACITOR 25V YR K 0.015U

C 48 GJ262101532402 C.CAPACITOR 25V YR K 0.015U

C 49 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 50 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 51 GJ264143312101 C.CAPACITOR AXIAL 50V B K 3

C 52 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 56 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 60 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 61 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 62 GJ264081202101 C.CAPACITOR 50V CH J 12PF

C 63 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 64 GJ264081202101 C.CAPACITOR 50V CH J 12PF

C 65 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 69 GJ264262222101 A.CAPACITOR 16V X M 0.0022U

C 70 GJ270192250332 E.CAPACITOR 50V M 2.2UF

C 71 GJ270121060332 E.CAPACITOR 16V M 10UF

C 77 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 98 GJ264141012101 C.CAPACITOR 50V B K 100PF

C 99 GJ264141012101 C.CAPACITOR 50V B K 100PF

C 101 GJ283101022432 M.CAPACITOR 50V K 0.001UF

C 102 GJ283105622432 M.CAPACITOR 50V K 0.0056UF

C 103 GJ270122260332 E.CAPACITOR 16V M 22UF

C 104 GJ282033932415 M.CAPACITOR 50V J 0.039UF

C 107 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 108 GJ270191050332 E.CAPACITOR 50V M 1UF

C 109 GJ283108232432 M.CAPACITOR 50V K 0.082UF

C 110 GJ283108232432 M.CAPACITOR 50V K 0.082UF

C 111 GJ283106822432 M.CAPACITOR 50V K 0.0068UF

C 112 GJ282034742415 M.CAPACITOR 50V J 0.47UF

C 113 GJ283102232432 M.CAPACITOR 50V K 0.022UF

C 114 GJ270122260332 E.CAPACITOR 16V M 22UF

C 115 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 117 GJ270191050332 E.CAPACITOR 50V M 1UF

C 119 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 120 GJ270121070332 E.CAPACITOR 16V M 100UF

C 121 GJ264142212101 C.CAPACITOR 50V B K 220PF

C 122 GJ270121070332 E.CAPACITOR 16V M 100UF

C 123 GJ270122280132 E.CAPACITOR 16V M 2200UF

C 124 GJ283101042432 M.CAPACITOR 50V K 0.1UF

C 125 GJ270122260332 E.CAPACITOR 16V M 22UF

C 130 GJ260772212412 C.CAPACITOR C 50V SL J 220P

C 134 GJ283105622432 M.CAPACITOR 50V K 0.0056UF

C 155 GJ264141812101 C.CAPACITOR 50V B K 180PF

C 201 GJ283101022432 M.CAPACITOR 50V K 0.001UF

C 202 GJ283105622432 M.CAPACITOR 50V K 0.0056UF

C 203 GJ270122260332 E.CAPACITOR 16V M 22UF

C 204 GJ282033932415 M.CAPACITOR 50V J 0.039UF

C 207 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 208 GJ270191050332 E.CAPACITOR 50V M 1UF

C 209 GJ283108232432 M.CAPACITOR 50V K 0.082UF

C 210 GJ283108232432 M.CAPACITOR 50V K 0.082UF

C 211 GJ283106822432 M.CAPACITOR 50V K 0.0068UF

C 212 GJ282034742415 M.CAPACITOR 50V J 0.47UF

C 213 GJ283102232432 M.CAPACITOR 50V K 0.022UF

C 214 GJ270122260332 E.CAPACITOR 16V M 22UF

C 215 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 217 GJ270191050332 E.CAPACITOR 50V M 1UF

C 219 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 220 GJ270121070332 E.CAPACITOR 16V M 100UF

C 221 GJ264142212101 C.CAPACITOR 50V B K 220PF

C 222 GJ270121070332 E.CAPACITOR 16V M 100UF

C 223 GJ270122280132 E.CAPACITOR 16V M 2200UF

C 224 GJ283101042432 M.CAPACITOR 50V K 0.1UF

C 225 GJ270122260332 E.CAPACITOR 16V M 22UF

C 230 GJ260772212412 C.CAPACITOR C 50V SL J 220P

C 234 GJ283105622432 M.CAPACITOR 50V K 0.0056UF

C 255 GJ264141812101 C.CAPACITOR 50V B K 180PF

C 303 GJ260771512412 C.CAPACITOR 50V SL J 150PF

C 304 GJ270114760332 E.CAPACITOR 10V M 47UF

C 305 GJ270122260332 E.CAPACITOR 16V M 22UF

C 306 GJ270114760332 E.CAPACITOR 10V M 47UF

C 308 GJ260771812412 C.CAPACITOR 50V SL J 180PF

C 309 GJ264261822101 C.CAPACITOR 16V X M 0.0018U

C 310 GJ283101822432 M.CAPACITOR 50V K 0.0018UF

C 312 GJ283106822432 M.CAPACITOR 50V K 0.0068UF

C 313 GJ270114760332 E.CAPACITOR 10V M 47UF

C 315 GJ283104722432 M.CAPACITOR 50V K 0.0047UF

C 318 GJ270146880132 E.CAPACITOR 25V VX M 6800UF

C 319 GJ270141060332 E.CAPACITOR 25V M 10UF

C 320 GJ270122270332 E.CAPACITOR 16V M 220UF

C 321 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 322 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 323 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 324 GJ283101022432 M.CAPACITOR 50V K 0.001UF

C 325 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 326 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 327 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 328 GJ270191050332 E.CAPACITOR 50V M 1UF

C 329 GJ270191040332 E.CAPACITOR 50V M 0.1UF

C 330 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 350 GJ270194750332 E.CAPACITOR 50V M 4.7UF

C 353 GJ270121060332 E.CAPACITOR 16V M 10UF

C 354 GJ270112270332 E.CAPACITOR 10V M 220UF

C 357 GJ270122260332 E.CAPACITOR 16V M 22UF

C 371 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 604 GJ270111070332 E.CAPACITOR 10V M VX 100UF

C 605 GJ270141060332 E.CAPACITOR 25V M 10UF

C 606 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 607 GJ264141022101 C.CAPACITOR 50V B K 1000PF

C 608 GJ270191050332 E.CAPACITOR 50V M 1UF

C 609 GJ264141012101 C.CAPACITOR 50V B K 100PF

C 610 GJ282032732415 M.CAPACITOR 50V J 0.027UF

C 611 GJ264264722101 A.CAPACITOR 16V X M 0.0047U

C 612 GJ264271032101 C.CAPACITOR 16V Y M 0.01UF

Item

Parts number Parts name Area

Remarks
