JVC RC-BZ6BU Service Manual

RC-BZ5LB/BZ5RD
3-9
Item
Parts number Parts name Area
Remarks
A
Q
316 2SA1015/YG/-T TRANSISTOR GJ872923115
Q
317 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
318 DTA143ESA-T D.TR.I.M DTA143ESA-TP
Q
601 2SA952/LK/-T TRANSISTOR TAPE
Q
631 2SA952/LK/-T TRANSISTOR TAPE
Q
851 2SA1037AK/RS/-X TRANSISTOR GJ872902649
Q
901 2SB772/QP/ TRANSISTOR
A
GJ312070021102
Q
902 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
903 8550C TRANSISTOR
A
GJ312080042204
Q
904 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
906 8550C TRANSISTOR
A
GJ312080042204
Q
907 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
908 2SB772/QP/ TRANSISTOR
A
GJ312070021102
Q
909 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
911 2SC2458/YG/-T TRANSISTOR GJ872923044
R 1 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 2 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 3 GJ250082702103 CARBON RESISTOR CF 1/6W J 27
R 4 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 7 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 9 GJ250084722103 CARBON RESISTOR CF 1/6W J 4.7K
R 13 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 18 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 20 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 24 GJ250086812103 CARBON RESISTOR CF 1/6W J 680
R 25 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 30 GJ250081832103 CARBON RESISTOR CF 1/6W J 18K
R 31 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 32 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 33 GJ250083312103 CARBON RESISTOR CF 1/6W J 330
R 35 GJ250082732103 CARBON RESISTOR CF 1/6W J 27K
R 36 GJ250082732103 CARBON RESISTOR CF 1/6W J 27K
R 37 GJ250085602103 CARBON RESISTOR CF 1/6W J 56
R 38 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 39 GJ250081212103 CF RESISTOR CF 1/6W J 120
R 42 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 44 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 47 GJ250082202103 CARBON RESISTOR CF 1/6W J 22
R 48 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 49 GJ250081832103 CARBON RESISTOR CF 1/6W J 18K
R 50 GJ250081832103 CARBON RESISTOR CF 1/6W J 18K
R 52 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 54 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 55 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 56 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 57 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 59 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 60 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 61 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 63 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 64 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 104 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 106 GJ250083932103 CF RESISTOR CF 1/6W J 39K
R 107 GJ250088202103 RES CF CF 1/6W J 82
R 108 GJ250081532103 CARBON RESISTOR CF 1/6W J 15K
R 119 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 121 GJ250088202103 RES CF CF 1/6W J 82
R 122 GJ250082292103 C.RESISTOR CF 1/6W J 2.2
R 123 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 124 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 125 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 127 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 131 GJ250081832103 CARBON RESISTOR CF 1/6W J 18K
R 132 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 133 GJ250081822103 CARBON RESISTOR CF 1/6W J 1.8K
R 134 GJ250083922103 CARBON RESISTOR CF 1/6W J 3.9K
R 135 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 137 GJ250086822103 CARBON RESISTOR CF 1/6W J 6.8K
R 204 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 206 GJ250083932103 CF RESISTOR CF 1/6W J 39K
R 207 GJ250088202103 RES CF CF 1/6W J 82
R 208 GJ250081532103 CARBON RESISTOR CF 1/6W J 15K
R 219 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 221 GJ250088202103 RES CF CF 1/6W J 82
R 222 GJ250082292103 C.RESISTOR CF 1/6W J 2.2
R 223 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 224 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 225 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 227 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 231 GJ250081832103 CARBON RESISTOR CF 1/6W J 18K
R 232 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 233 GJ250081822103 CARBON RESISTOR CF 1/6W J 1.8K
R 234 GJ250083922103 CARBON RESISTOR CF 1/6W J 3.9K
R 235 GJ250084732103 CARBON RESISTOR CF 1/6W J 47K
R 237 GJ250086822103 CARBON RESISTOR CF 1/6W J 6.8K
R 302 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 303 GJ250084752103 RES CF CF 1/6W J 4.7M
R 304 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 305 GJ250081822103 CARBON RESISTOR CF 1/6W J 1.8K
R 306 GJ250081822103 CARBON RESISTOR CF 1/6W J 1.8K
R 307 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 310 GJ250081232103 CARBON RESISTOR CF 1/6W J 12K
R 311 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 312 GJ250084312103 C.RESISTOR CF 1/6W J 430
R 313 GJ250081202103 C.RESISTOR CF 1/6W J 12
R 316 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 317 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 318 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 320 GJ250085622103 CARBON RESISTOR CF 1/6W J 5.6K
R 321 GJ250085622103 CARBON RESISTOR CF 1/6W J 5.6K
R 328 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 332 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 356 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 360 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 361 GJ250084742103 CARBON RESISTOR CF 1/6W J 470K
R 371 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 372 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 373 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 601 GJ250081132103 CARBON RESISTOR CF 1/6W J 11K
R 603 GJ250081252103 FUSE RESISTOR CF 1/6W J 1.2M
R 605 GJ250082742103 CARBON RESISTOR CF 1/6W J 270K
R 606 GJ250081542103 CARBON RESISTOR CF 1/6W J 150K
R 607 GJ250082732103 CARBON RESISTOR CF 1/6W J 27K
R 609 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 610 GJ250081542103 CARBON RESISTOR CF 1/6W J 150K
R 612 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 613 GJ250081212103 CF RESISTOR CF 1/6W J 120
R 614 GJ250081002103 CARBON RESISTOR CF 1/6W J 10
R 615 GJ250081202103 C.RESISTOR CF 1/6W J 12
R 616 GJ250089102103 CARBON RESISTOR CF 1/6W J 91
R 621 GJ250083302103 CARBON RESISTOR CF 1/6W J 33
R 622 GJ250083302103 CARBON RESISTOR CF 1/6W J 33
R 623 GJ250083302103 CARBON RESISTOR CF 1/6W J 33
R 631 GJ250083312103 CARBON RESISTOR CF 1/6W J 330
R 632 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 633 GJ250082732103 CARBON RESISTOR CF 1/6W J 27K
Electrical parts list ( Main board )
