JVC RC-BZ6BU

RC-BZ6BU
3-21
Item
Parts number Parts name Area
Remarks
A
L 602 GJ141033431 INDUCTOR 100UH 10%
Q
40
L 901 VQP0028-330Z INDUCTOR 33UH EL0606RA
Q
1 2SC2668/O/T TRANSISTOR GJ312020351201
Q
101 2SC2001/LK/-T TRANSISTOR GJ872914247
Q
103 2SC3330/ST/-T TRANSISTOR GJ312030091201
Q
201 2SC2001/LK/-T TRANSISTOR GJ872914247
Q
203 2SC3330/ST/-T TRANSISTOR GJ312030091201
Q
302 KRA102M-T D.TRANSISTOR GJ872903715
Q
303 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
304 2SA1015/YG/-T TRANSISTOR GJ872923115
Q
305 KRC102M-T D.TRANSISTOR GJ872903658
Q
306 8550C TRANSISTOR GJ312080042204
Q
308 DTC143ES TRANSISTOR GJ872992166
Q
309 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
310 DTC143ESA-T TR I/M GJ872902947
Q
311 2SC2001/LK/-T TRANSISTOR GJ872914247
Q
312 2SC2001/LK/-T TRANSISTOR GJ872914247
Q
313 2SC2001/LK/-T TRANSISTOR GJ872914247
Q
315 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
316 2SA1015/YG/-T TRANSISTOR GJ872923115
Q
317 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
318 DTC143ESA-T TR I/M GJ872902947
Q
601 2SA952/LK/-T TRANSISTOR GJ312090101202
Q
631 2SA952/LK/-T TRANSISTOR GJ312090101202
Q
901 2SB772/QP/ TRANSISTOR
A
GJ312070021102
Q
902 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
903 8550C TRANSISTOR
A
GJ312080042204
Q
904 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
906 8550C TRANSISTOR
A
GJ312080042204
Q
907 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
908 2SB772/QP/ TRANSISTOR
A
GJ312070021102
Q
909 2SC2458/YG/-T TRANSISTOR GJ872923044
Q
911 2SC2458/YG/-T TRANSISTOR GJ872923044
R 1 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 2 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 3 GJ250082702103 CARBON RESISTOR 1/6W J 27
R 4 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 7 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 9 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 13 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 18 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 20 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 24 GJ250086812103 CARBON RESISTOR 1/6W J 680
R 25 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 30 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 31 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 32 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 33 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 35 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 36 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 37 GJ250085602103 CARBON RESISTOR 1/6W J 56
R 38 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 39 GJ250081212103 CF RESISTOR 1/6W J 120
R 42 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 44 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 47 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 48 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 49 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 50 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 52 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 54 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 55 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 56 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 57 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 59 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 60 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 61 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 63 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 64 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 101 GJ250083022103 CARBON RESISTOR 1/6W J 3.0K
R 102 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 103 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 104 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 106 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 107 GJ250088202103 RES CF 1/6W J 82
R 108 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 109 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 110 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 111 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 112 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 113 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 114 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 116 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 117 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 119 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 120 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 121 GJ250088202103 RES CF 1/6W J 82
R 122 GJ250082292103 C.RESISTOR 1/6W J 2.2
R 123 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 124 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 134 GJ250083922103 CARBON RESISTOR 1/6W J 3.9K
R 136 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 137 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 201 GJ250083022103 CARBON RESISTOR 1/6W J 3.0K
R 202 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 203 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 204 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 206 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 207 GJ250088202103 RES CF 1/6W J 82
R 208 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 209 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 210 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 211 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 212 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 213 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 214 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 216 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 217 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 219 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 220 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 221 GJ250088202103 RES CF 1/6W J 82
R 222 GJ250082292103 C.RESISTOR 1/6W J 2.2
R 223 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 224 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 234 GJ250083922103 CARBON RESISTOR 1/6W J 3.9K
R 236 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 237 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 302 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 303 GJ250084752103 RES CF 1/6W J 4.7M
R 304 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 305 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 306 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 307 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 308 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 309 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 310 GJ250081232103 CARBON RESISTOR 1/6W J 12K
Electrical parts list ( Main board )
Block No. 01
Item
Parts number Parts name Area
Remarks
A
