27
TROUBLESHOOTING
SPECIFICATIONS
CD player section
Type : Compact disc player
Signal detection
system : Non-contact optical pickup
Number of channels : 2 channels
Frequency response : 20 Hz - 20,000 Hz
Signal-to-noise ratio : 90 dB
Wow & flutter : Less than measurable limit
Radio section
Frequency range : FM 87.5-108 MHz
AM: (MW) 522-1,629 kHz
(LW) 144-288 kHz
Antennas : Telescopic antenna for FM
Ferrite core antenna for AM (MW/LW)
Tape deck section
Track system : 4-track 2-channel stereo
Motor : Electronic governor DC motor for capstan
Heads : Hard permalloy head for recording/playback, 2 gap ferrite
head for erasure (Combination head)
Frequency response : 60 - 14,000 Hz
(with CrO
2 tape)
Wow & flutter : 0.15% (WRMS)
Fast wind time : Approx. 150 sec (C-60 cassette)
General
Speakers
(Impedance) Full range: 8 cm x 2 (4 Ω)
Super woofer : 16 cm x 2 ( 4 Ω)
Power output : (Max.)
20W (10W +10W) at 4 Ω (full range)
40W (20W +20W) at 4 Ω, 60Hz (woofer)
(10% THD)
10W (5W + 5W) at 4 Ω (full range)
30W (15W + 15W) at 4 Ω, 60Hz (woofer)
Input terminals : AUX IN (300 mV/47 kΩ)
MIC/GUITAR INPUT (6.3 mm dia. plug)
(Matching impedance:
MIC: 200 Ω – 2 kΩ, GUITAR: 100 kΩ – 1 MΩ)
Output terminals : PHONES (Output level: 0 - 12 mW/ch, 32 Ω, Matching
impedance: 16 Ω - 1 kΩ)
Power requirements : AC 230 V, 50 Hz
DC 15V (“R20/D (13F)” batteries x 10)
Ext.DC12V (car battery via optional CA-R120E car
adapter)
Power consumption : 43 W (with
SW ON)
1.4 W (with
SW STANDBY)
Dimensions : 690 (W) x 239 (H) x 296 (D) mm, including knobs
Mass : 9.5 kg (without batteries)
10.6 kg (with batteries)
Accessories provided : AC power cord x 1
Remote control unit (RM-RXVB99E) x 1
R6/AA (15F) batteries x 2
Shoulder strap x 1
Design and specifications are subject to change without notice.
(Tuner Section)
÷ Reception is noisy.
* Try adjusting the antenna.
* Is there a TV set or computer device near the unit?
(Timer Section)
÷ Timer operation does not start.
* Is the current time set correctly?
* Is the timer mode indicator ( ) displayed?
(Remote Control)
÷ Remote control is impossible.
* Are the batteries in the remote control exhausted?
* Is the remote sensor section exposed to bright light (direct sunlight,
etc.)?
Notes:
÷ When the above remedies do not help
Many operations of this unit are performed by the control of a
microprocessor. If none of the buttons function, unplug the power cord
and remove all the batteries, wait for a while, then load the batteries
again and plug it back in. Reset the correct values for the clock and
timer.
÷ Before making an important recording, be sure to make a test recording
first to check that the deck, etc. is working correctly.
What appears to be trouble is not always serious. First make sure....
÷ Power cannot be turned on.
* Is the power cord unplugged?
÷ No sound from the speakers.
* Are headphones connected?
÷ Clock time is blinking in the display.
* Was there a power failure?
* Was the power cord unplugged while the memory back-up batteries
were not installed?
(CD Player Section)
÷ The CD player does not play.
* Is the CD upside down?
* Is the CD dirty?
* Is there condensation on the lens? (See “Cleaning the lens” on page
26.)
÷ A certain portion of the CD does not play correctly.
* Is the CD scratched?
* Is there condensation on the lens?
÷ When the operation stops.
* Switch to STANDBY and then to ON again.
(Cassette Deck Section)
÷ Playback sound is at a very low level.
* Is the head dirty?
÷ The ONE TOUCH REC button does not function.
* Have the safety tabs of the cassette been broken off?
