RX-SO9VTN
|
COMPU
LINK-3
Connections
Other
Audio
Connections
‘AC
OUTLET:
SWITCHED:
Page
6
1-8
(No.
20376)
COMPU
LINK-3
SYNCHRO
jacks
on
the
back
of
the
receiver
connect
the
COMPU
LINK
Temote
control
system.
This
system
connects
other
JVC
audio
components
with
the
receiver
to
make
listening
and
recording
more
convenient.
Touse
this
system,
attach
the
cables
provided
with
your
VC
components
to
the
COMPU
LINK-3
SYNCHRO
jacks
on
the
rear
panel
of
each
component.
Then
connect
the
cables
to
the
receiver.
NOTES:
*
COMPU
LINK-3
is
an
upgraded
version
of
COMPU
LINK-1.
If
your
equipment
provides
COMPU
LINK-I
jacks,
you
can
still
connect
your
equipment,
but
slight
imperfections
may
result.
Automatic
Power
ON/OFF,
for
example,
may
not
always
function
properly.
°
*
Refer
to
page
24
for
details
about
the
COMPU
LINK
remote
control
system.
ZX
CAUTION!
Do
not
connect
Tape
Deck
2
to
the
COMPU
UNK
jacks.
It
may
cause
the
COMPU
LINK
system
to
malfunction.
Use
the
socket
on
the
back
of
the
receiver
to
connect
the
power
supply
of
any
audio
components.
By
pressing
the
POWER
switch
on
the
remote
control,
you
can
tum
the
receiver,
and
all
connected
components,
on
or
off
at
the
same
time.
In
the
United
States,
AC
outlets
have
a
capacity
of
150
watts.
4S
CAUTION!
Do
not
connect
any
components
that
consume
more
power
than
the
capacity
of
the
AC
outlet.
This
capacity
is
indicated
below
the
socket
on
the
back
of
the
receiver.
Basic
Connections
for
Connect
the
audio
signal
jacks
of
your
video
components
to
the
AUDIO
jacks
on
the
receiver.
Video
Components
Connect
the
video
signal
(composite)
jacks
to
the
VIDEO
jacks.
If
you
are
connecting
a
VCR,
connect
the
output
jacks
on
the
VCR
to
the
jacks
marked
IN
(PLAY)
on
the
receiver,
and
the
input
jacks
to
those
market
OUT
(REC).
NOTE:
Keep
the
connecting
cables
for
your
TV,
VCR,
and
antenna
away
from
the
power
cord
leading
from
the
back
of
the
receiver.
The
power
cord
may
cause
noise
or
screen
interference.
We
recommend
that
you
use
coaxial
cable
to
connect
the
antenna,
since
it
is
well-shielded
against
interference.
VIDEO
DISC
PLAYER
Audio
Outpat
Page
7
(No.
20376)
1-9
