JVC RX-6010VBK Service Manual

RX-6010VBK/RX-6012VSL
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
R 440 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 441 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 442 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 445 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 446 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 449 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 450 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
RY302 QSK0109-001 RELAY
A
RY303 QSK0109-001 RELAY
A
RY304 QSK0109-001 RELAY
A
R1301 QRL022J-562 UNF OMF RESISTOR
A
5.6K 5% 1/2W
R1302 QRZ9005-100X F RESISTOR
A
10 1/0W
R1303 QRJ146J-562X UNF C RESISTOR
A
5.6K 5% 1/4W
R1304 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1305 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1306 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R1307 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1308 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1309 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1310 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1311 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1312 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1313 QRZ9005-100X F RESISTOR
A
10 1/0W
R1314 QRJ146J-103X UNF C RESISTOR
A
10K 5% 1/4W
R1315 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1316 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1317 QRJ146J-223X UNF C RESISTOR
A
22K 5% 1/4W
R1318 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1319 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R1352 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1353 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1354 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1355 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R1356 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1357 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1358 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1359 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1360 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1361 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1362 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1363 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1364 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1365 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1366 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1367 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1370 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R1371 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R1372 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R1373 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R1374 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
ST304 QNB0103-002 SPK TERMINAL
ST305 QNB0001-002 SPK TERMINAL
(Main board)
