3-9
Power amp. board
Block No. [0][3][0][0]
R1515 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R1571 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1572 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1573 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1574 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1575 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1576 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1579 NRSA63J-301X MG RESISTOR 300
Ω 1/16W J
R1580 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1581 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R1582 NRSA63J-162X MG RESISTOR 1.6k
Ω 1/16W J
R1583 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R1584 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
CN101 QGD2504C1-03Z CONNECTOR (1-3)
CN402 QGF1205C1-27 CONNECTOR FFC/FPC (1-27)
CN411 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN421 QGB2510J1-14 CONNECTOR B-B (1-14)
CN431 QGB2510J1-11 CONNECTOR B-B (1-11)
CN441 QGB2510J1-07 CONNECTOR B-B (1-7)
CN461 QGB2510J1-08 CONNECTOR B-B (1-8)
CN471 QGA2501C1-03 CONNECTOR W-B (1-3)
CN472 QGA2501C1-02 CONNECTOR W-B (1-2)
CN473 QGA2501C1-03 CONNECTOR W-B (1-3)
CN481 QGB2510J1-14 CONNECTOR B-B (1-14)
CN482 QGB2510J1-07 CONNECTOR B-B (1-7)
CN491 QGB2510J1-04 CONNECTOR B-B (1-4)
CN701 QGF1205F1-14 CONNECTOR FFC/FPC (1-14)
CN702 QGF1205F1-27 CONNECTOR FFC/FPC (1-27)
CN704 WJS0020-002A SKT.WIRE ASSY
CN714 QGA2001F1-03 CONNECTOR W-B (1-3)
DI701 QLF0132-001 FL TUBE
EP401 QNZ0136-001Z EARTH PLATE
FL401 QQR1372-001 LPF
FL402 QQR1372-001 LPF
FW501 QUM213-10DGZ4 PARA RIBON WIRE
J101 QNS0022-001 JACK
J1501 QNN0391-001 PIN JACK
JS701 QSW1017-002 JOG VOLUME
JS702 QSW1051-001 ROTARY ENCODER
S721 QSW0683-001Z PUSH SW
S722 QSW0683-001Z PUSH SW
S723 QSW0683-001Z PUSH SW
S724 QSW0683-001Z PUSH SW
S725 QSW0683-001Z PUSH SW
S726 QSW0683-001Z PUSH SW
S727 QSW0683-001Z PUSH SW
S728 QSW0683-001Z PUSH SW
S729 QSW0683-001Z PUSH SW
S730 QSW0683-001Z PUSH SW
S731 QSW0683-001Z PUSH SW
S732 QSW0683-001Z PUSH SW
S734 QSW0683-001Z PUSH SW
S735 QSW0683-001Z PUSH SW
S736 QSW0683-001Z PUSH SW
S738 QSW0683-001Z PUSH SW
S739 QSW0683-001Z PUSH SW
S740 QSW0683-001Z PUSH SW
S741 QSW0683-001Z PUSH SW
S742 QSW0683-001Z PUSH SW
S743 QSW0683-001Z PUSH SW
S745 QSW0683-001Z PUSH SW
S746 QSW0683-001Z PUSH SW
S750 QSW0683-001Z PUSH SW
S751 QSW0683-001Z PUSH SW
S752 QSW0683-001Z PUSH SW
S757 QSW0683-001Z PUSH SW
X701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC501 NJM2246D IC
Q202 KRC105M-T DIGI TRANSISTOR
 Q203 KTC3203/OY/-T TRANSISTOR
Q205 KTC3200/GL/-T TRANSISTOR
Q206 KRC105M-T DIGI TRANSISTOR
Q208 KRC105M-T DIGI TRANSISTOR
Q209 KRC105M-T DIGI TRANSISTOR
Q210 KRC105M-T DIGI TRANSISTOR
Q301 2SC2240/L/-T TRANSISTOR
Q302 2SC2240/L/-T TRANSISTOR
Q303 2SC2240/L/-T TRANSISTOR
Q304 2SC2240/L/-T TRANSISTOR
Q305 KTA1268/GL/-T TRANSISTOR
Q306 KTA1268/GL/-T TRANSISTOR
Q307 KTC3200/GL/-T TRANSISTOR
Q308 KTC3200/GL/-T TRANSISTOR
Q309 2SD637/QR/ TRANSISTOR
Q310 2SD637/QR/ TRANSISTOR
Q311 KTC3200/GL/-T TRANSISTOR
Q312 KTC3200/GL/-T TRANSISTOR
Q313 KTA1268/GL/-T TRANSISTOR
Q314 KTA1268/GL/-T TRANSISTOR
 Q315 2SD2389/OPY/-F6 TRANSISTOR
 Q316 2SD2389/OPY/-F6 TRANSISTOR
 Q317 2SB1559/OPY/-F6 TRANSISTOR
 Q318 2SB1559/OPY/-F6 TRANSISTOR
Q319 KTA1268/GL/-T TRANSISTOR
Q320 KTA1268/GL/-T TRANSISTOR
Q501 KTA1267/YG/-T TRANSISTOR
Q502 KTC3199/GL/-T TRANSISTOR
Q503 KRC101M-T TRANSISTOR
Q504 KTA1267/YG/-T TRANSISTOR
Q505 KTC3199/GL/-T TRANSISTOR
Q801 2SC2240/L/-T TRANSISTOR
Q802 2SC2240/L/-T TRANSISTOR
Q803 2SC2240/L/-T TRANSISTOR
Q804 2SC2240/L/-T TRANSISTOR
Q805 KTA1268/GL/-T TRANSISTOR
Q806 KTA1268/GL/-T TRANSISTOR
Q809 2SD637/QR/ TRANSISTOR
Q810 2SD637/QR/ TRANSISTOR
Q811 KTC3200/GL/-T TRANSISTOR
Q812 KTC3200/GL/-T TRANSISTOR
Q813 KTA1268/GL/-T TRANSISTOR
Q814 KTA1268/GL/-T TRANSISTOR
 Q815 2SD2389/OPY/-F6 TRANSISTOR
 Q816 2SD2389/OPY/-F6 TRANSISTOR
 Q817 2SB1559/OPY/-F6 TRANSISTOR
 Q818 2SB1559/OPY/-F6 TRANSISTOR
Q819 KTA1268/GL/-T TRANSISTOR
Q820 KTA1268/GL/-T TRANSISTOR
Q901 2SC2240/L/-T TRANSISTOR
Q903 2SC2240/L/-T TRANSISTOR
Q905 KTA1268/GL/-T TRANSISTOR
Q909 2SD637/QR/ TRANSISTOR
Q911 KTC3200/GL/-T TRANSISTOR
Q913 KTA1268/GL/-T TRANSISTOR
 Q915 2SD2389/OPY/-F6 TRANSISTOR
 Q917 2SB1559/OPY/-F6 TRANSISTOR
Q919 KTA1268/GL/-T TRANSISTOR
 D201 10DDA20-FD DIODE
 D202 11ES2-T4 DIODE
 D203 10DDA20-FD DIODE
 D204 11ES2-T4 DIODE
 D206 11ES2-T4 DIODE
 D207 11ES2-T4 DIODE
 D208 11ES2-T4 DIODE
 D209 11ES2-T4 DIODE
D210 1SS133-T2 DIODE
D211 MTZJ6.8C-T2 Z DIODE
D212 11ES2-T4 DIODE
D217 MTZJ8.2C-T2 Z DIODE
