RX-7010RBK/RX-7012RSL
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
R 915 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 921 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 923 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 925 QRE141J-361Y C RESISTOR 360 5% 1/4W
R 927 QRE141J-911Y C RESISTOR 910 5% 1/4W
R 929 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 931 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 933 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 935 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 937 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 939 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 941 QRE141J-181Y C RESISTOR 180 5% 1/4W
R 943 QRZ0218-R22 EMIT RESISTOR
A
1/2W
R 945 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 947 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 949 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 951 QRJ125J-330 UNF C RESISTOR
A
33 5% 1/2W
R 953 QRL022J-100 UNF OMF RESISTOR
A
10 5% 1/2W
R 955 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 957 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 959 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 961 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
RY202 QSK0098-001 RELAY
A
RY203 QSK0109-001 RELAY
A
R1331 QRL022J-471 UNF OMF RESISTOR
A
470 5% 1/2W
R1332 QRL022J-471 UNF OMF RESISTOR
A
470 5% 1/2W
T 202 QQT0281-002 POWER TRANSF
A
TA201 QNZ0079-001Z TAB
TA202 QNZ0079-001Z TAB
TH301 QAD0012-202 THERMISTOR
A
TH302 QAD0012-202 THERMISTOR
A
TH801 QAD0012-202 THERMISTOR
A
TH802 QAD0012-202 THERMISTOR
A
TH901 QAD0012-202 THERMISTOR
A
VR301 QVP0008-102Z SEMI V RESISTOR
VR302 QVP0008-102Z SEMI V RESISTOR
(Power amp board)
