JVC RX-7010RBK - Page 30

RX-7010RBK/RX-7012RSL
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
Item
Parts number Parts name Area
Remarks
A
IC402 TC9164AN IC
IC403 BA15218N IC
IC551 NJM2246D IC
IC552 NJM2246D IC
J 401 QNN0389-001 PIN JACK PHONO
J 402 QNN0168-001 PIN JACK
J 403 QNN0168-001 PIN JACK
J 551 QND0083-001 S JACK
J 552 QND0083-001 S JACK
J 553 QND0025-001 S JACK DBS
K 551 QQR0621-001Z FERRITE BEADS
K 552 QQR0621-001Z FERRITE BEADS
L1351 QQLZ005-R45 INDUCTOR
L1352 QQLZ005-R45 INDUCTOR
L1353 QQLZ005-R45 INDUCTOR
L1354 QQLZ005-R45 INDUCTOR
L1355 QQLZ005-R45 INDUCTOR
Q
553 KTA1267/YG/-T TRANSISTOR
Q
554 KTA1267/YG/-T TRANSISTOR
Q
571 KTA1267/YG/-T TRANSISTOR
Q
572 KTA1267/YG/-T TRANSISTOR
Q
573 KRC110M-T TRANSISTOR
Q
574 KRC110M-T TRANSISTOR
Q
1301 KTA1046/Y/ TRANSISTOR
A
Q
1302 KTC3200/GL/-T TRANSISTOR
Q
1303 KTA1268/GL/-T TRANSISTOR
Q
1304 KTC3199/GL/-T TRANSISTOR
Q
1305 2SD2395/EF/ TRANSISTOR
Q
1306 KTA1023/OY/-T TRANSISTOR
Q
1307 KTC3200/GL/-T TRANSISTOR
Q
1351 KRC109M-T D TRANSISTOR
Q
1352 KRC109M-T D TRANSISTOR
Q
1353 KRC109M-T D TRANSISTOR
Q
1354 KRC109M-T D TRANSISTOR
Q
1355 KRC109M-T D TRANSISTOR
Q
1356 KRC109M-T D TRANSISTOR
Q
1357 KRC109M-T D TRANSISTOR
Q
1358 KRC109M-T D TRANSISTOR
R 401 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 402 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 403 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 404 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 405 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 406 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 407 QRE141J-393Y C RESISTOR 39K 5% 1/4W
R 408 QRE141J-393Y C RESISTOR 39K 5% 1/4W
R 409 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R 410 QRE141J-474Y C RESISTOR 470K 5% 1/4W
R 411 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 412 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 421 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 422 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 423 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 424 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 425 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 426 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 429 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 430 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 431 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 432 QRE141J-471Y C RESISTOR 470 5% 1/4W
R 435 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 436 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 440 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 441 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 442 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 445 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 446 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 449 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 450 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 551 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 552 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 553 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 554 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 555 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 556 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 557 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 558 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 559 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 560 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 561 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 562 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 563 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 564 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R 565 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 566 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 571 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 572 QRE141J-391Y C RESISTOR 390 5% 1/4W
R 573 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 574 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 581 QRJ146J-6R8X UNF C RESISTOR
A
6.8 5% 1/4W
RY301 QSK0109-001 RELAY
A
RY302 QSK0109-001 RELAY
A
RY303 QSK0109-001 RELAY
A
RY304 QSK0109-001 RELAY
A
R1301 QRL022J-562 UNF OMF RESISTOR
A
5.6K 5% 1/2W
R1302 QRZ9005-100X F RESISTOR
A
10 1/0W
R1303 QRJ146J-562X UNF C RESISTOR
A
5.6K 5% 1/4W
R1304 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1305 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1306 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R1307 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1308 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1309 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1310 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1311 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1312 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R1313 QRZ9005-100X F RESISTOR
A
10 1/0W
R1314 QRJ146J-103X UNF C RESISTOR
A
10K 5% 1/4W
R1315 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1316 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1317 QRJ146J-223X UNF C RESISTOR
A
22K 5% 1/4W
R1318 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1319 QRE141J-473Y C RESISTOR 47K 5% 1/4W
R1351 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1352 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1353 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1354 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1355 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R1356 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1357 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1358 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R1359 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1360 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1361 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
(Main board)
