JVC RX-7032VSL Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10469-017A FRONT PANEL
2 LV43338-002A JVC MARK
3 LV21438-001A LENS
4 LV10767-002A SUB PANEL
5 LV34032-002A CONTROL PLATE
6 LV21437-002A SEALING DOOR
7 LV34086-002A DOOR COVER
8 QYSPSGU2030N TAP SCREW 2mm x 3mm(x3)
9 LV43357-001A DOOR SPRING
10 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm
11 LV20939-004A PUSH BUTTON
12 LV42096-001A INDICATOR
13 LV21442-002A P.BUTTON(TUNER)
14 LV21439-002A P.BUTTON(DSP)
15 LV21440-002A P.BUTTON(SOURCE
16 LV21443-002A P.BUTTON(ADJUST
17 LV32486-003A P.BUTTON ASSY
18 QYSBSF2610Z SCREW 2.6mm x 10mm(x2)
19 QYSBSF2610Z SCREW 2.6mm x 10mm(x2)
20 QYSBSF2610Z SCREW 2.6mm x 10mm(x8)
21 QUQ412-0517CJ FFC WIRE
22 QUQ412-0930DJ FFC WIRE
23 QYSDSG3006Z SCREW 3mm x 6mm(x4)
24 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x3)
25 LV10019-006A CHASSIS BASE
26 LV10471-002A FRONT BRACKET
27 QYSDSG3006Z SCREW 3mm x 6mm(x7)
28 LV42094-003A H.P BKT
29 QYSBSG3006Z TAPPING SCREW 3mm x 6mm
30 VKZ4150-001 SPECIAL NUT
31 E68587-223SM CB BKT (x3)
32 QYSBST3006Z TAPPING SCREW M3 x 6mm(x3)
33 QZF6018-003 FOOT 60mm x 18mm(x4)
34 QYSBST3010Z TAPPING SCREW M3 x 10mm(x4)
35 LV21444-001A HEAT SINK
36 QYSBSG3012E SCREW 3mm x 12mm(x12)
37 LV42098-001A C.B BKT
38 QYSBST3006Z TAPPING SCREW 3mm x 6mm
39 LV32433-001A H.S BRACKET(R)
40 LV32434-001A H.S BRACKET(L)
41 QYSBSG3008Z TAPPING SCREW 3mm x 8mm(x4)
42 QYSBST3006Z TAPPING SCREW M3 x 6mm(x2)
43 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x2)
44 QYSBST3006Z TAPPING SCREW M3 x 6mm(x4)
45 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x2)
46 E65923-003 TAPPING SCREW
47 LV30225-0B2A SPACER
48 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x3)
49 QYSBSG3008M TAPPING SCREW 3mm x 8mm(x3)
50 QYSBSG3006Z TAPPING SCREW 3mm x 6mm(x3)
51 QYSBSG3006Z TAPPING SCREW 3mm x 6mm
 52 QQT0397-002 POWER TRANSF
53 QYSDSTL4008Z ASSY SCREW M4 x 8mm(x4)
54 LV10768-013A REAR PANEL
7032VSL
E,
7032VSL
EN
54 LV10768-014A REAR PANEL
7032VSL
EV
55 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
56 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm
57 QYSBST3006M TAPPING SCREW M3 x 6mm(x2)
58 LV30225-011A SPACER
59 FMYH4004-001 PLASTIC RIVET (x2)
60 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm
61 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x4)
62 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
63 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
64 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x6)
65 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm
66 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x6)
67 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm
 68 QMPK250-205-JV POWER CORD(EU) 2.05m BLACK
 69 QZW0033-001 STRAIN RELIEF
70 LV20038-012A/S/ TOP COVER
71 LV30225-088A SPACER
72 LV30077-006A PROTECT SHEET
73 QYSBSGY3008M SPECIAL SCREW 3mm x 8mm(x3)
74 E406308-004 SPECIAL SCREW (x4)
75 LV43463-002A VOL KNO ASSY
76 LV43458-002A JOG KNOB ASSY
 77 QMF51W2-3R15-J8 FUSE
F 1 3.15A
AC250V
 78 QMF51E2-R10-J1 FUSE
F 2 0.1A
AC250V
 79 QMF51W2-2R0-J8 FUSE
F 61 F 62 2A
AC250V(x2)
80 E307572-001 FASTENER
81 E409396-003 CAUTION LABEL
82 QAU0278-003 TUNER
83 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x3)
84 QUQ412-1124DJ FFC WIRE
