RX-8010RBK/RX-8012RSL
3-4
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 LV10469-003A FRONT PANEL 1 RX-8010RBK
LV10469-008A FRONT PANEL 1 RX-8012RSL
2 VJD5429-002SS JVC MARK 1 RX-8012RSL
VJD5429-001SS JVC MARK 1 RX-8010RBK
3 LV20950-006A LENS 1
4 LV10470-002A SUB PANEL 1 RX-8012RSL
LV10470-001A SUB PANEL 1 RX-8010RBK
5 LV20939-002A PUSH BUTTON 1 RX-8012RSL
LV20939-003A PUSH BUTTON 1 RX-8010RBK
6 LV42096-001A INDICATOR 1 POWER
7 LV20951-001A PUSH BUTTON 1 TUNER
8 LV20940-001A P.BUTTON ASSY 1 RX-8010RBK
LV20940-002A P.BUTTON ASSY 1 RX-8012RSL
9 LV20944-001A P.BUTTON ASSY 1 RX-8010RBK
LV20944-002A P.BUTTON ASSY 1 RX-8012RSL
10 LV20942-001A PUSH BUTTON 1 RX-8010RBK
LV20942-002A PUSH BUTTON 1 RX-8012RSL
11 LV32486-002A PUSH BUTTON 1 RX-8012RSL
LV32486-001A P.BUTTON ASSY 1 RX-8010RBK
12 LV42095-002A FL SCREEN 1 FL
13 QYSBSF2610Z SCREW 2 FRONT C.B
14 QYSBSF2610Z SCREW 2 FRONT C.B
15 QYSBSF2610Z SCREW 8 FRONT C.B FL
16 QUQ412-0815CJ FFC WIRE 1
17 QUQ412-1030CJ FFC WIRE 1
18 QYSDSG3006Z SCREW 4 FRONT D
19 QYSBSG3006Z T.SCREW 3 FRONT U
20 LV10019-003A CHASSIS BASE 1
21 EXO150010H09S11 FELT SPACER 1 FOR C.BASE
22 LV10471-002A FRONT BRACKET 1
23 QYSDSG3006Z SCREW 7 C.B-F.B
24 LV42094-002A H.P. BKT 1
25 QYSBSG3006Z T.SCREW 1 H.P BKT-F.B
26 VKZ4150-001 SPECIAL NUT 1
27 E68587-223SM CB BKT 3
28 QYSBST3006Z T.SCREW 3 C.B-BKT
29 QZF6018-003 FOOT 4 RX-8012RSL
QZF6018-001 FOOT 4 RX-8010RBK
31 QYSBST3010Z T.SCREW 4 FOOT
32 LV20984-002A HEAT SINK 1
33 E73525-003SS SCREW 10 TR
34 LV42098-001A C.B BKT 1 PRI/SEC C.B
35 QYSBST3006Z T.SCREW 1 C.B BKT
36 LV32433-001A H.S BRACKET
(
R
)
1
37 LV32434-001A H.S BRACKET
(
L
)
1
38 QYSBSG3008Z T.SCREW 4 H.S-BKT
39 QYSBSG3006Z T.SCREW 2 H.S BKT-F.BKT
40 QYSBSG3006Z T.SCREW 2 H.S BKT
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
41 QYSBST3006Z T.SCREW 4 H.S BKT-CHASSIS
42 QYSBSG3006Z T.SCREW 2 M.C.B
43 E65923-003 TAPPING SCREW 1 M.C.B
44 LV30225-0B2A SPACER 1
45 QYSBSG3006Z T.SCREW 3 H.S-C.B
46 QYSBSG3006Z T.SCREW 3 P.C.B-CHASSIS
47 QYSBSG3006Z T.SCREW 1 C.B-CHASSIS
48 QQT0325-002 POWER TRANSF
A
1 MATSUSHITA
49 QYSDSTL4008Z SPECIAL SCREW 4 P.TRANS
50 LV10472-014A REAR PANEL 1 RX-8012RSL
LV10472-013A REAR PANEL 1 RX-8010RBK
51 QYSBSGY3008M SPECIAL SCREW 3 R.P-C.BASE
52 QYSBSGY3008M SPECIAL SCREW 1 R.P-ud---
53 QYSBSGY3008M SPECIAL SCREW 2 TUNER
54 FMYH4004-001 PLASTIC RIVET 1 A.INPUT
55 QYSBSGY3008M SPECIAL SCREW 4 A.INPUT
56 QYSBSGY3008M SPECIAL SCREW 3 V.INPUT
57 QYSBSGY3008M SPECIAL SCREW 3 VIDEO
58 QYSBSGY3008M SPECIAL SCREW 4 S VIDEO
59 QYSBSGY3008M SPECIAL SCREW 6 DIGITAL
60 QYSBSGY3008M SPECIAL SCREW 4 COMPONENT
61 QYSBSGY3008M SPECIAL SCREW 4 SPK C.B
62 E409257-001 GND TERMINAL 1
63 QMPK150-200-JD POWER CORD
A
1
64 QZW0033-001 STRAIN RELIEF
A
1
65 LV20038-009A/S/ TOP COVER 1 RX-8010RBK
LV20038-010A/S/ TOP COVER 1 RX-8012RSL
66 QYSBSGY3008M SPECIAL SCREW 3
67 E406308-004 SPECIAL SCREW 4 RX-8012RSL
E406308-003 SPECIAL SCREW 4 RX-8010RBK
68 LV32435-003A VOL KNOB 1 RX-8010RBK
LV32435-004A VOL KNOB 1 RX-8012RSL
69 QMF51E2-3R15-J1 FUSE
A
1 F1
70 QMF51E2-2R0-J1 FUSE
A
2 F61
,
F62
72 E409396-002 CAUTION LABEL 1
73 E3400-444 FELT SPACER 2 FS400
,
FS401
74 QYSBSG3008E T.SCREW 3
75 QYSBSG3008E T.SCREW 3
76 LV20952-001A PUSH BUTTON 1 RDS/M.ROOM
77 QYSBSG3006Z T.SCREW 1
78 LV30077-004A PROTECT SHEET 1 RX-8010RBK
LV30077-006A PROTECT SHEET 1 RX-8012RSL
79 LV32488-004A JACK COVER 1 RX-8012RSL
LV32488-003A JACK COVER 1 RX-8010RBK
80 QMF51E2-R10-J1 FUSE
A
1 F2
81 E307572-001 FASTENER 1
(General assembly)
