RX-8010RBK/ RX-8012RSL
1-6
Remove the two screws L' attaching the heat sink
from the rear side of main board.
Disconnect the connect CN701, CN702, CN703,
CN705 and CN706 on the main board.
Remove the ten screws K and four screws L
attaching the heat sink.
1.
2.
3.
Removing the Heat sink
(See Fig.15 and 16)
Prior to performing the following procedure, remove
the top cover, the rear panel and audio board.
Cut off the tie band fixing the harness.
Disconnect the harness from connector CN811 on
the power supply board respectively.
Disconnect the harness from connector CN881 on
the main board.
Remove the four screws I and the two screws J
attaching the main board.
1.
2.
3.
4.
Removing the main board (See Fig.14)
Fig.14
Main board
rear side
Heat sink
L
L
K
K
K
L'
L'
Fig.15
Fig.16
Main
board
I
CN881
I
J
J
J
I
I
Tie band
CN811
Main board
Heat sink
CN701
CN703
CN705
CN702
CN706
To Next Page
