JVC RX-8030VBK Service Manual

1-2 (No.MB103)
SPECIFICATION
Designs & specifications are subject to change without notice.
Amplifier
Output Power
At Stereo operation Front ch 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic
distortion. (IEC 268-3/DIN)
At Surround operation Front ch 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic
distortion.
Center ch 100 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic distortion.
Surround ch 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic
distortion.
Surround Back ch 100 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/
Impedance (1 kHz)
PHONO IN (MM) : 2.5 mV/47 kΩ
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO IN : 200 mV/47 kΩ
CD IN, CDR IN, TAPE/MD IN : 200 mV/47 kΩ
Audio Input (DIGITAL IN)* Coaxial DIGITAL 1 (DVD) : 0.5 V(p-p)/75 Ω
Optical DIGITAL 2 (CD), DIGITAL 3 (TV), DIGITAL 4 (CDR) : -21 dBm to -15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level PRE OUT : 1 V
Recording Output Level VCR 1 OUT, VCR 2 OUT, CDR OUT, TAPE/MD OUT : 200 mV
Digital output Optical : DIGITAL OUTPUT
Signal wave length : 660 nm
Output level : -21 dBm to -15 dBm
Signal-to-Noise Ratio
('66 IHF/DIN)
PHONO IN : 70 dB/66 dB
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO : 87 dB/67 dB
CD IN, CDR IN, TAPE/MD IN : 87 dB/67 dB
Frequency Response (8 Ω) PHONO IN : 20 Hz to 20 kHz (±1 dB)
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO : 20 Hz to 100 kHz (+1 dB, -3 dB)
CD IN, CDR IN, TAPE/MD IN : 20 Hz to 100 kHz (+1 dB, -3 dB)
RIAA Phono Equalization ±1 dB (20 Hz to 20 kHz)
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz (±8 dB)
Bass boost +6 dB ±1 dB at 100 Hz
Video
Video Input Sensitivity/
Impedance
Composite video : DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS
IN, VIDEO
1 V(p-p)/75 Ω
S-video : DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO (Y: luminance) : 1 V(p-p)/75 Ω
(C: chrominance, burst) : 0.286 V(p-p)/75 Ω
Component video : DVD IN, DBS IN (Y: luminance) : 1 V(p-p)/75 Ω
(PB/PR) : 0.7 V(p-p)/75 Ω
Video Output Level Composite video : VCR 1 OUT, VCR 2 OUT, MONITOR OUT 1 V(p-p)/75 Ω
S-video : VCR 1 OUT, VCR 2 OUT, MONITOR OUT (Y: luminance) : 1 V(p-p)/75 Ω
(C: chrominance, burst) : 0.286 V(p-p)/75 Ω
Component video (Y: luminance) : 1 V(p-p)/75 Ω
(PB/PR) : 0.7 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural : 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity Monaural : 16.0 dBf (1.7 µV/75 Ω)
Stereo : 37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at REC OUT 35 dB at 1 kHz
AM tuner
Tuning Range 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements AC 110 V/127 V/220 V/230 V - 240 V , adjustable with the voltage selector, 50 Hz/60 Hz
Power Consumption 250 W (at operation)
4.5 W (in standby mode)
Dimensions (W × H × D) 435 mm × 157 mm × 425 mm
Mass 12.3 kg
