JVC RX-E100RSL

46
Specifications
Designs & specifications are subject to change without notice.
Amplifier
Output Power At Stereo operation:
Front channels:
50 W per channel, min. RMS, Both channels
driven into 8 Ω at 1kHz with no more than 0.9%
total harmonic distortion. (IEC268-3/DIN)
At Surround operation:
Front channels: 50 W per channel, min. RMS, driven into 8 Ω at 1 kHz with no
more than 0.8% total harmonic distortion.
Center channel: 50 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than
0.8% total harmonic distortion.
Rear channels: 50 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no
more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz): DVD, STB, VCR, TV, TAPE: 180 mV/47 kΩ
Audio Input (DIGITAL IN)* : Coaxial: DIGITAL 1 (DVD): 0.5 Vp-p/75 Ω
Optical: DIGITAL 2 (STB): –21 dBm to –15 dBm (660 nm ±30 nm)
*Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround
(with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level: VCR, TV, TAPE: 180 mV
Signal-to-Noise Ratio (’66 IHF/DIN): DVD, STB, VCR, TV, TAPE: 85 dB/62 dB
Frequency Response (8 Ω): DVD, STB, VCR, TV, TAPE: 20 Hz to 20 kHz (±1 dB)
Tone Control: Bass (100 Hz): ±10 dB
Treble (10 kHz): ±10 dB
Bass Boost: +6 dB ± 1 dB at 70 Hz
Video
Video Input Sensitivity/Impedance (1 kHz):
Composite video: DVD, STB, VCR, TV: 1 Vp-p/75 Ω
S-VIDEO: DVD, STB, VCR: (Y:luminance): 1 Vp-p/75 Ω
(C:chrominance): 0.286 Vp-p/75 Ω
RGB: DVD, STB, VCR: 0.7 Vp-p/75 Ω
Video Output Level/Impedance (1 kHz):
Composite video: VCR, TV: 1 Vp-p/75 Ω
S-VIDEO: TV: (Y:luminance): 1 Vp-p/75 Ω
(C:chrominance): 0.286 Vp-p/75 Ω
RGB: TV: 0.7 Vp-p/75 Ω
Signal-to-Noise Ratio (S/N): 45 dB
Synchronize: Negative
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
Usable Sensitivity: Monaural: 17.0 dBf (1.95 µV/75 Ω)
50 dB Quieting Sensitivity: Monaural: 21.3 dBf (3.2 µV/75 Ω)
Stereo: 41.3 dBf (31.5 µV/75 Ω)
Signal-to-Noise Ratio (IHF-A weighted): Monaural: 78 dB at 85 dBf
Stereo: 73 dB at 85 dBf
Total Harmonic Distortion: Monaural: 0.4% at 1 kHz
Stereo: 0.6% at 1 kHz
Stereo Separation at REC OUT: 35 dB at 1 kHz
Alternate Channel Selectivity: 60 dB: (±400 kHz)
Frequency Response: 30 Hz to 15 kHz: (+0.5 dB, –3 dB)
AM (MW/LW) tuner
Tuning Range: MW: 522 kHz to 1 629 kHz
LW: 144 kHz to 288 kHz
Usable Sensitivity: Loop antenna 400 µV/m (MW)
Signal-to-Noise Ratio: 50 dB (100 mV/m)
General
Power Requirements: AC 230V , 50 Hz
Power Consumption: 110 W (at operation)
2 W (in standby mode)
Dimensions (W x H x D): 17
3
/16 in. x 3
15
/16 in. x 15
11
/16 in.
(435 mm x 100 mm x 398 mm)
Mass: 16.4 lbs (7.4 kg)
