3-18(No.YD091)
DC/DC Converter board
Block No. [1][1]
B5403 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN501 QGF1040C1-07 CONNECTOR FFC/FPC (1-7)
CN701 QGF1207C1-04 CONNECTOR FFC/FPC (1-4)
CN901 QGF1207C1-13 CONNECTOR FFC/FPC (1-13)
CN2601 QGF1040C1-08 CONNECTOR FFC/FPC (1-8)
CN2602 QGB1231L1-11 CONNECTOR B-B (1-11)
CN3014 QGF1040C1-07 CONNECTOR FFC/FPC (1-7)
CN3102 QGF1207C1-15 CONNECTOR FFC/FPC (1-15)
CN3103 QGB1231L1-19 CONNECTOR B-B (1-19)
CN3104 QGF1207C1-15 CONNECTOR FFC/FPC (1-15)
CN3901 QGF1207C1-06 CONNECTOR FFC/FPC (1-6)
CN5402 QGF1207C1-15 CONNECTOR FFC/FPC (1-15)
CN5403 QGA2001C1-05 CONNECTOR W-B (1-5)
CN5404 QGF1207C1-08 CONNECTOR FFC/FPC (1-8)
CP5401 QMFZ050-1R5X-E FUSE 1.5A 125V
CP5402 QMFZ050-1R5X-E FUSE 1.5A 125V
GN2 QNZ0136-001Z EARTH PLATE
J841 GP1FA553TZ0F IC OPT OUT
J852 QNN0096-001 PIN JACK COAX_OUT
J901 QNZ0609-001 AV JACK LIN+VDROUT
J902 QNN0528-001 PIN JACK LINE_OUT
J903 QNN0587-002 PIN JACK COMP_OUT
J906 QNS0100-001 3.5 JACK C BOX CTL
J953 QNZ0093-001
BNC CONNECTOR
V.OUT BNC
K851 NQR0227-004X FERRITE BEADS
K852 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K853 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7301 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7302 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7303 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K7304 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
OT1 LP31378-001A BOSS(MECHA)3
OT2 LP31379-001A BOSS(MECHA)4 (x2)
W1 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W4 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W8 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W9 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W10 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W11 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W12 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W13 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W14 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W15 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W16 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W17 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W18 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W19 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W20 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W21 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W22 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W23 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W24 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W25 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W26 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W27 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W28 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W29 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W30 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W31 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W32 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W33 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W34 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W36 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W37 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W38 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W39 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W40 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W41 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W42 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W43 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W44 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W45 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W46 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W47 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W48 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W49 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W50 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W51 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
W52 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W53 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W54 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W55 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W56 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W57 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W58 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W59 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W60 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W61 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W62 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W63 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W64 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W65 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W66 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
X201 QAX0614-001Z CRYSTAL 8.867238MHz
X701 QAX0740-001 CRYSTAL 4.433619MHz
X3001 QAX0445-001 CRYSTAL 32.768kHz
X3002 QAX0527-001 CRYSTAL 10.000000MHz
Symbol No.
Part No. Part Name Description Local
PW1 LPA20041-02B DC/DC CONVERTER BOARD ASSY
IC5701 BD9851EFV-X IC
IC5710 QS5U27-W MOS FET
Q5720 RTQ035P02-W MOS FET
D5710 RB520S-30-X SB DIODE
D5720 RB520S-30-X SB DIODE
D5721 SX34-X SB DIODE
D5721 or RB051L-40-X SB DIODE
C5710 NCB31HK-681X C CAPACITOR 680pF 50V K
C5711 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5712 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5713 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5714 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C5716 NDC31HJ-151X C CAPACITOR 150pF 50V J
C5720 NCB31HK-681X C CAPACITOR 680pF 50V K
C5721 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5722 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5723 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5724 NCB10JK-106X C CAPACITOR 10uF 6.3V K
C5726 NCB31HK-331X C CAPACITOR 330pF 50V K
C5727 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5730 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5731 NDC31HJ-101X C CAPACITOR 100pF 50V J
C5732 NCB31CK-223X C CAPACITOR 0.022uF 16V K
R5710 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5711 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R5712 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5713 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5720 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5721 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R5722 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5723 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5730 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5731 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5732 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
L5710 NQL82EN-100X COIL 10uH N
L5720 NQR0562-001X CHOKE COIL
CN5701 QGG2009M1-13 CONNECTOR (1-13)
CN5702 QGG2009M1-03 CONNECTOR (1-3)
K5710 NQR0499-002X FERRITE BEADS
K5720 NQR0499-002X FERRITE BEADS
Symbol No.
Part No. Part Name Description Local
