(No.YD091)3-19
Operation/jack board
Block No. [2][7]
Display/Switch board
Block No. [2][8]
DV jack board
Block No. [3][6]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10314-01B5 OPERATON JACK BOARD ASSY
C7202 NDC31HJ-471X C CAPACITOR 470pF 50V J
C7203 NDC31HJ-471X C CAPACITOR 470pF 50V J
C7204 NDC31HJ-471X C CAPACITOR 470pF 50V J
C7205 NDC31HJ-471X C CAPACITOR 470pF 50V J
C7206 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7211 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7212 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R7202 QRE141J-750Y C RESISTOR 75
Ω
1/4W J
R7206 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7207 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7211 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7212 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7213 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R7214 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7215 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
L7202 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
L7203 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
CN7201 QGF1208C1-15 CONNECTOR FR MAIN
J7201 QNN0592-002 PIN JACK FRONT AV
J7204 QND0085-001 S JACK FRONT S
S7211 QSW0381-001Z TACT SWITCH INPUT SEL
S7212 QSW0381-001Z TACT SWITCH POWER
S7213 QSW0381-001Z TACT SWITCH DISPLAY
S7214 QSW0381-001Z TACT SWITCH OUTPUT SEL
S7215 QSW0381-001Z TACT SWITCH DV EJECT
Symbol No.
Part No. Part Name Description Local
PW1 LPA10314-01B4 OPERATON JACK BOARD ASSY
IC7001 PT6315 IC
IC7002 GP1UM281XKVF IR DETECT UNIT
IC7002 or PNA4652M00XB IR DETECT UNIT 38kHz
Q7001 UN221L-X DIGI TRANSISTOR
Q7001 or DTC143EKA-X DIGI TRANSISTOR
Q7001 or RT1N431C-X TRANSISTOR
Q7002 UN221L-X DIGI TRANSISTOR
Q7002 or DTC143EKA-X DIGI TRANSISTOR
Q7002 or RT1N431C-X TRANSISTOR
Q7003 UN221L-X DIGI TRANSISTOR
Q7003 or DTC143EKA-X DIGI TRANSISTOR
Q7003 or RT1N431C-X TRANSISTOR
D7003 1SS133-T2 SI DIODE
D7003 or 1SS270A-T2 SI DIODE
D7004 1SS133-T2 SI DIODE
D7004 or 1SS270A-T2 SI DIODE
D7005 1SS133-T2 SI DIODE
D7005 or 1SS270A-T2 SI DIODE
D7012 1SS133-T2 SI DIODE
D7012 or 1SS270A-T2 SI DIODE
D7013 1SS133-T2 SI DIODE
D7013 or 1SS270A-T2 SI DIODE
D7014 1SS133-T2 SI DIODE
D7014 or 1SS270A-T2 SI DIODE
D7021 MTZJ9.1B-T2 Z DIODE
D7041 SLR-343MC-T LED VHS
D7042 SLR-343VC-T LED VHS REC
D7043 SLR-343VC-T LED HDD REC
D7044 SLR-343VC-T LED DVD REC
D7046 SLR-343MC-T LED HDD
D7047 SLR-343MC-T LED DVD
C7001 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C7002 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7003 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C7006 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C7008 QERF1AM-227Z E CAPACITOR 220uF 10V M
C7010 NCF31HZ-473X C CAPACITOR 0.047uF 50V Z
C7011 NCF31HZ-473X C CAPACITOR 0.047uF 50V Z
R7001 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7002 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7003 QRE141J-823Y C RESISTOR 82k
Ω
1/4W J
R7005 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R7006 QRE141J-472Y C RESISTOR 4.7k
Ω
1/4W J
R7007 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R7009 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7010 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7013 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R7014 QRE141J-333Y C RESISTOR 33k
Ω
1/4W J
R7015 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7022 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R7041 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R7042 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R7043 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R7044 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R7046 QRE141J-101Y C RESISTOR 100
Ω
1/4W J
R7047 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
CN7001 QGF1209F2-15 CONNECTOR MAIN
DI7001 QLF0143-001 FL TUBE
HD1 PQ34949-1-1 FL HOLDER(L) FOR DI7001
HD2 PQ34950-1-1 FDP HOLDER(R) FOR DI7001
S7004 QSW0381-001Z TACT SWITCH A.DUB
S7012 QSW0381-001Z TACT SWITCH DV/HDD/DVD
S7013 QSW0381-001Z TACT SWITCH FF
S7014 QSW0381-001Z TACT SWITCH PAUSE
S7015 QSW0381-001Z TACT SWITCH STOP
S7023 QSW0381-001Z TACT SWITCH REC MODE
S7024 QSW0381-001Z TACT SWITCH INSERT
S7025 QSW0381-001Z TACT SWITCH REPLAY
S7032 QSW0381-001Z TACT SWITCH OPEN/CLOSE
S7033 QSW0381-001Z TACT SWITCH REW
S7034 QSW0381-001Z TACT SWITCH REC
S7035 QSW0381-001Z TACT SWITCH PLAY
W41 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W42 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W43 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W44 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
PW1 LPA10314-01B3 JACK BOARD ASSY
CN4104 QGA2001C1-06 CONNECTOR DIGITAL
J4112 QNZ0675-001 DV CONNECTOR F-DV
K4101 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4102 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4103 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4104 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4105 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K4106 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W4102 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W4104 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W4105 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W4106 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
