3-20(No.YD091)
DV main board
Block No. [5][0]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10270-06A DV MAIN BOARD ASSY
IC1001 MM1561JF-X IC
IC1002 MM1572FN-X IC
IC1003 MM1573AN-X IC
IC1004 MM1572KN-X IC
IC1005
S-80823CNNB-G-W
IC
IC1501 D703040YJ13-A IC(MCU)
IC1501 or D70F3040YJ13-A IC(MCU)
IC1502 TC7W14FK-X IC
IC1503 TC7W04FU-X IC(DIGITAL)
IC1504 CAT25C16SI-X IC
IC2001 JCY0152-2 IC
IC2101 JCY0177-W IC
IC2102
SN74AHC1G04DC-X
IC
IC3001 JCP8029 IC
IC3101 TC7SH04F-X IC(DIGITAL)
IC3102 TC7SH04F-X IC(DIGITAL)
IC3151 M62366GP-D-X IC
IC3501 NJM2538V-X IC
IC3701 AK4550VT-X IC
IC3702 BA15218F-XE IC
IC3702 or RC4558D-X IC
IC3703 BA15218F-XE IC
IC3703 or RC4558D-X IC
IC4001 JCY0132 IC
IC4002 TC7SH00FU-X IC(DIGITAL)
Q1001 2SB1302/ST/-X TRANSISTOR
Q1002 DTC144EE-X DIGI TRANSISTOR
Q1003 2SB1302/ST/-X TRANSISTOR
Q1004 DTC144EE-X DIGI TRANSISTOR
Q1005 2SB1302/ST/-X TRANSISTOR
Q1006 DTC144EE-X DIGI TRANSISTOR
Q1007 2SB1302/ST/-X TRANSISTOR
Q1008 DTC144EE-X DIGI TRANSISTOR
Q1501 2SC4617/RS/-X TRANSISTOR
Q1502 2SC4617/RS/-X TRANSISTOR
Q1503 2SC4617/RS/-X TRANSISTOR
Q1511 DTA114EE-X DIGI TRANSISTOR
Q1512 UMC3N-W DIGI TRANSISTOR
Q1513 UMC3N-W DIGI TRANSISTOR
Q3101 2SA1576A/RS/-X TRANSISTOR
Q3102 2SA1576A/RS/-X TRANSISTOR
Q3111 2SA1576A/RS/-X TRANSISTOR
Q3112 HN1B04FU/YG/-X PAIR TRANSISTOR
Q3113 2SC4081/RS/-X TRANSISTOR
Q3114 2SC4081/S/-X TRANSISTOR
Q3115 DTC144EE-X DIGI TRANSISTOR
Q3131 2SA1576A/RS/-X TRANSISTOR
Q3132 HN1B04FU/YG/-X PAIR TRANSISTOR
Q3133 2SC4081/RS/-X TRANSISTOR
Q3135 DTC144EE-X DIGI TRANSISTOR
Q3501 DTC144EE-X DIGI TRANSISTOR
Q3502 2SA1576A/RS/-X TRANSISTOR
Q3503 2SA1576A/RS/-X TRANSISTOR
Q3521 2SA1576A/RS/-X TRANSISTOR
Q3522 2SA1576A/RS/-X TRANSISTOR
Q4002 2SC4083/NP/-X TRANSISTOR
Q4003 2SC4083/NP/-X TRANSISTOR
Q4004 2SC4083/NP/-X TRANSISTOR
D1501 SB007W03Q-X SB DIODE
D1502 SB007W03Q-X SB DIODE
D1503 SB007W03Q-X SB DIODE
D1504 SB007W03Q-X SB DIODE
D1505 SB007W03Q-X SB DIODE
D1506 SB007W03Q-X SB DIODE
D2002 EC2C01C-TR-X VARI CAP DIODE
D2003 EC2C01C-TR-X VARI CAP DIODE
D2004 EC2C01C-TR-X VARI CAP DIODE
C1001 NEX60JM-227X E CAPACITOR 220uF 6.3V M
C1002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1003 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C1004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1005 NEAF0JM-107X E CAPACITOR 100uF 6.3V M
C1006 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1007 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1008 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1009 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1010 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1012 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1014 NBE21AM-106X
TA E CAPACITOR
10uF 10V M
C1015 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1016 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1017 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1018 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1019 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1020 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1021 NBE21AM-106X
TA E CAPACITOR
10uF 10V M
C1022 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1023 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1024 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1025 NBE21AM-106X
TA E CAPACITOR
10uF 10V M
C1026 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1027 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1028 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C1029 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C1030 NBE21AM-106X
TA E CAPACITOR
10uF 10V M
C1501 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1502 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1504 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1508 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1509 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C1510 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C1515 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1516 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1517 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1518 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C1520 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1522 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1523 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1531 NDC31HJ-100X C CAPACITOR 10pF 50V J
C1532 NDC31HJ-220X C CAPACITOR 22pF 50V J
C2001 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2006 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2007 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2010 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2014 NDC31HJ-330X C CAPACITOR 33pF 50V J
C2015 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C2016 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2017 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C2018 NCB31EK-472X C CAPACITOR 4700pF 25V K
C2019 NDC31HJ-271X C CAPACITOR 270pF 50V J
C2020 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2022 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2023 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2024 NDC31HJ-6R0X C CAPACITOR 6pF 50V J
C2025 NDC31HJ-6R0X C CAPACITOR 6pF 50V J
C2026 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C2027 NDC31HJ-270X C CAPACITOR 27pF 50V J
C2028 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C2031 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2032 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2036 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2037 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2038 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2039 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2040 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2041 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2042 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2043 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2044 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2047 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C2048 NCB31HK-222X C CAPACITOR 2200pF 50V K
C2051 NEAF0JM-226X E CAPACITOR 22uF 6.3V M
Symbol No.
Part No. Part Name Description Local
