3-24(No.YD091)
Junction board
Block No. [9][2]
Symbol No.
Part No. Part Name Description Local
PW1 LPA10314-01B2 JUNCTION BOARD ASSY
IC5501 RT9167A-33PS-X IC
IC5502 MM1689BH-X IC
IC5503 R1171S501B-X IC
IC7101 MM1623XF-X IC
IC8001 RC4558D-X IC
IC8001 or BA15218F-XE IC
IC8002 AK5357ET-X IC
IC8002 or AK5357VT-X IC
IC8201 RC4558D-X IC
IC8201 or BA15218F-XE IC
IC8202 AK4385ET-X IC
IC8202 or AK4385VT-X IC
Q5504 2SC3576-JVC-T TRANSISTOR
Q5504 or 2SD2144S/VW/-T TRANSISTOR
Q5505 RT1P441C-X DIGI TRANSISTOR
Q5505 or UN2113-X TRANSISTOR
Q5508 2SA1585S/QR/-T TRANSISTOR
Q5509 RT1N141C-X DIGI TRANSISTOR
Q5509 or UN2211-X TRANSISTOR
Q7101 2SB709A/QR/-X TRANSISTOR
Q7101 or 2SA1037AK/QR/-X TRANSISTOR
Q7101 or 2SA1530A/QR/-X TRANSISTOR
Q8001
2SC2412K/QRS/-X
TRANSISTOR
Q8001 or 2SD601A/QRS/-X TRANSISTOR
Q8001 or
2SC3928A/QRS/-X
TRANSISTOR
Q8002
2SC2412K/QRS/-X
TRANSISTOR
Q8002 or 2SD601A/QRS/-X TRANSISTOR
Q8002 or
2SC3928A/QRS/-X
TRANSISTOR
Q8003 DTC144WKA-X DIGI TRANSISTOR
Q8003 or UN221E-X TRANSTSTOR
Q8003 or RT1N44HC-X DIGI TRANSISTOR
Q8004 DTC144WKA-X DIGI TRANSISTOR
Q8004 or UN221E-X TRANSTSTOR
Q8004 or RT1N44HC-X DIGI TRANSISTOR
Q8005 DTA144WKA-X TRANSISTOR
Q8005 or UN211E-X DIGI TRANSISTOR
Q8005 or RT1P44HC-X DIGI TRANSISTOR
D5503 MTZJ27D-T2 Z DIODE
D5510 SBO40-T2 SB DIODE
D5510 or 1S4-T2 SB DIODE
D5512 1G3-T2 SI DIODE
D5512 or 1A3G-T2 SI DIODE
D5512 or 10EDB20-T2 SI DIODE
D5513 1G3-T2 SI DIODE
D5513 or 1A3G-T2 SI DIODE
D5513 or 10EDB20-T2 SI DIODE
D5515 SBO40-T2 SB DIODE
D5515 or 1S4-T2 SB DIODE
D5516 RS1G-X FR DIODE
D5516 or 1SR156-400-X SI DIODE
D5517 RS1G-X FR DIODE
D5517 or 1SR156-400-X SI DIODE
C5501 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5502 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5504 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5505 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5506 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5507 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5508 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5509 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C5510 NCB31HK-471X C CAPACITOR 470pF 50V K
C5511 QEZ0654-477Z E CAPACITOR 470uF 10V M
C5515 QEZ0653-227Z E CAPACITOR 220uF 6.3V M
C5520 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5522 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C5524 NCB11AK-106X C CAPACITOR 10uF 10V K
C5526 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5533 QETN1CM-477Z E CAPACITOR 470uF 16V M
C7101 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7102 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7103 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C7104 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C7105 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C7106 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C7107 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C7109 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7112 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C7123 NDC31HJ-120X C CAPACITOR 12pF 50V J
C7124 NDC31HJ-6R0X C CAPACITOR 6pF 50V J
C7141 NDC31HJ-820X C CAPACITOR 82pF 50V J
C7142 NDC31HJ-820X C CAPACITOR 82pF 50V J
C8001 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8003 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8005 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8007 NDC31HJ-101X C CAPACITOR 100pF 50V J
C8009 QETN1CM-106Z E CAPACITOR 10uF 16V M
C8010 QETN1CM-106Z E CAPACITOR 10uF 16V M
C8011 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8013 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C8014 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8015 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C8016 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8051 QETN0JM-337Z E CAPACITOR 330uF 6.3V M
C8052 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8053 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8054 QETN0JM-337Z E CAPACITOR 330uF 6.3V M
C8055 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8056 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8057 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8201 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C8202 NCB31HK-471X C CAPACITOR 470pF 50V K
C8203 NCB31HK-471X C CAPACITOR 470pF 50V K
C8204 NCB31HK-472X C CAPACITOR 4700pF 50V K
C8205 NCB31HK-471X C CAPACITOR 470pF 50V K
C8206 NCB31HK-472X C CAPACITOR 4700pF 50V K
C8207 NCB31HK-471X C CAPACITOR 470pF 50V K
C8208 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C8209 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C8210 QEKC0JM-337Z E CAPACITOR 330uF 6.3V M
C8231 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C8232 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R5504 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R5505 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5507 NRSA63D-683X MG RESISTOR 68k
Ω
1/16W D
R5508 NRSA63D-393X MG RESISTOR 39k
Ω
1/16W D
R5509 NRSA63D-393X MG RESISTOR 39k
Ω
1/16W D
R5510 NRSA63D-333X MG RESISTOR 33k
Ω
1/16W D
R5511 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5512 QRE141J-821Y C RESISTOR 820
Ω
1/4W J
R5513 QRE141J-821Y C RESISTOR 820
Ω
1/4W J
R5516 QRZ9051-680X FUSI RESISTOR 68
Ω
0.25W J
R7101 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R7102 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7146 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7147 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7148 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R7149 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R7150 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R7152 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R7153 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R8001 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8002 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8003 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8004 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8005 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8006 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8007 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8008 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R8009 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R8010 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R8011 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R8012 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R8013 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R8014 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R8015 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
To Next Page
