JVC SR-DVM700EU - Page 117

(No.YD091)3-25
D-SUB board
Block No. [9][7]
R8016 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R8017 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8018 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R8019 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R8051 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R8052 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8201 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R8202 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R8203 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R8204 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R8205 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R8206 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R8207 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R8208 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R8209 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R8210 NRSA63D-512X MG RESISTOR 5.1k Ω 1/16W D
R8211 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R8212 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R8213 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R8214 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R8215 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R8216 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R8217 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8219 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R8220 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R8221 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R8222 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R8231 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R8232 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R8233 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L7101 QQL29BJ-100Z P COIL 10uH J
L7102 QQL071J-6R8Y COIL 6.8uH J
L8001 QQL29BJ-220Z P COIL 22uH J
L8002 QQL29BJ-220Z P COIL 22uH J
B5504 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7101 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7107 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7112 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B7118 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN5501 QGF1208C1-19 CONNECTOR FROM REG
CN5502 QGA2001C1-06 CONNECTOR TO DIGITAL
CN5503 QGA2001C1-08 CONNECTOR W-B (1-8)
CN5505 LPA20041-02B D/D CONV P ASSY
CN7102 QGB1231M1-19 CONNECTOR SYS
CN7106 QGF1040C1-04 CONNECTOR DIGI JLIP
CN7107 QGF1207C1-13 CONNECTOR V OUT
CN7108 QGB2027M3-28S CONNECTOR B-B (1-28)
CN7109 QGB2027M4-20S CONNECTOR B-B (1-20)
CN7121 QGB2027M9-14 CONNECTOR DV JACK2
CN7123 QGF1207C1-04 CONNECTOR VIDEO IN 2
CN7124 QGF1207C1-04 CONNECTOR JIG(JVC DR
CN7126 QGA2001C1-06 CONNECTOR DV JACK
CN7127 QGA2001C1-06 CONNECTOR DV JACK DV
CN8001 QGB1231M1-11 CONNECTOR AUDIO
 CP5501 QMFZ053-2R0Z-J1 FUSE 2A
 CP5502 QMFZ053-3R0Z-J1 FUSE 3A
 CP5503 QMFZ053-2R0Z-J1 FUSE 2A
K4111 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K4112 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K4113 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K4114 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K7101 NQR0129-002X FERRITE BEADS
K7102 NQR0129-002X FERRITE BEADS
K7103 NQR0129-002X FERRITE BEADS
K7104 NQR0129-002X FERRITE BEADS
K8001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K8002 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K8201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K8202 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
KA4113 NQR0169-001X EMI FILTER
KA4114 NQR0169-001X EMI FILTER
W1 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W2 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W6 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W7 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W8 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
W9 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W10 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W11 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W12 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W13 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W14 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W15 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
W16 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W17 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W18 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W19 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W22 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W23 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W24 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W25 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W26 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
W28 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
PW1 LPA10314-01B7 D - SUB BOARD ASSY
IC7401 MAX3221CDB-X IC
C7401 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7402 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7403 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7404 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7405 NCB31CK-104X C CAPACITOR 0.1uF 16V K
CN7401 QGF1040C1-04 CONNECTOR TO DIGITAL
J7401 QNZ0587-001 D CONNECTOR RS232C
 Symbol No. Part No. Part Name Description Local
