3. [3] Middle catcher assembly/ [4] Reel cover assembly
Fig.4-5-3
Note 3a:
Once the reel cover assembly has been removed, the
parts located below it tend to slip out easily: Be careful.
Note 3b:
When attaching these screws, screwing order (a),(b),( c)
4. [5] Pinch roller arm assembly/[6] Sub brake assembly/[7] Band arm plate sub assembly/ [8] Tension arm sub assembly
Fig.4-5-4
Fig.4-5-4a
Fig.4-5-4b
Note 4a:
When attaching this part, fit it in the boss (L7) on the
charge arm assembly.
Note 4b:
When attaching or removing this part, take care of the
handling of the band section.
Note 4c:
After fitting the spring on the shaft, engage it with hook
[a] first then with hook [b] .
After attaching it, set it to the positioning shown in
"Step 3" and confirm that band arm plate sub assembly
[7] can be rotated in the direction of the arrow as shown
below.
13
(
S2
)
(
L6
)
(
L6
)
<Note3a>
(a)
(b)
(c)
Apply grease
12
(
S2
)
<Note3b>
10
(
S2
)
<Note3b>
11
(
S2
)
<Note3b>
[
4
]
[
3
]
(
W1
)
(
W2
)
14
(
S3
)
(
P2
)
(
L9
)
(
L7
)
(
L8
)
(
W1
)
(
P1
)
(
P3
)
<Note 4c>:
How to install the spring
<Note4a>
<Note4b>
NOTE4c
Step 1
Step 2
Step 3
Hook [a]
Hook [b]
[
7
]
[
8
]
[
5
]
[
6
]
sub brake (Take up)
OK NG
spring hooked
reverse-side
To Next Page
