(No.YD125<Rev.001>)3-1
PARTS LIST
[SR-HD1250US, SR-HD1500US, SR-HD1500KR,
SR-HD1250EU, SR-HD1500EU, SR-HD1500ER,
SR-HD1500AG, SR-HD1500AC]
* SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with
specified part numbers.
* BEWARE OF BOGUS PARTS
Parts that do not meet specifications may cause trouble in regard to safety and
performance. We recommend that genuine JVC parts be used.
* (x_) in a description column shows the number of the used part.
- Contents -
Exploded view of general assembly and parts list
Electrical parts list
Packing materials and accessories parts list
3-2
3-4
3-8
To Next Page
