JVC TH-A5

54
English
Specifications
Center unit (XV-THA5)
Amplifier section
Front/Center/Rear:
35 watts per channel, min. RMS at 6 ohms as 1 kHz,
with no more than 10 % total harmonic distortion.
Subwoofer:
60 watts per channel, min. RMS at 3 ohms as 100 Hz,
with no more than 10 % total harmonic distortion.
Audio section
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
AUX (“AUX IN”): 500 mV/47 kΩ
Video section
Color System: NTSC/PAL
Horizontal Resolution: 480 lines
Signal-to-Noise Ratio: 68 dB
Output Level Composite: 1.0 V(p-p)/75 Ω
S-video-Y: 1.0 V(p-p)/75 Ω
S-video-C: 0.286 V(p-p)/75 Ω
Component-Y: 1.0 V(p-p)/75 Ω
Component-C
B/CR: 0.7 V(p-p)/75 Ω
Tuner section
Tuning Range FM: 87.5 MHz – 108.0 MHz
AM: 531 kHz – 1 602 kHz
(at 9 kHz intervals)
530 kHz – 1 600 kHz
(at 10 kHz intervals)
Usable Sensitivity FM: 8.0 dBf (0.9 µV/75 Ω)
AM loop antenna: 650 µV/m
General
Power Requirements: AC 110 V – 127 V/220 V – 240 V
,
adjustable with the voltage selector,
50 Hz/60 Hz
Power Consumption: 120 W (at operation)
2 W (in standby mode)
Dimensions (W × H × D): 350 mm × 80 mm × 300 mm
Mass: 6.3 kg
Subwoofer (SP-WA5)
Speaker: 20 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 60 W
Impedance: 3 Ω
Frequency Range: 25 Hz to 200 Hz
Dimensions (W × H × D) 219 mm × 324 mm × 320 mm
Mass: 6.2 kg
Satellite Speakers (SP-XSA5)
Speakers: 7 cm × 4 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 35 W
Impedance: 6 Ω
Frequency Range: 90 Hz to 20 kHz
Dimensions (W × H × D): 65 mm × 144 mm × 105 mm
Mass: 420 g
Center Speaker (SP-XCA5)
Speakers: 7 cm × 4 cm
Bass-reflex, Magnetically Shielded
Power Handling Capacity: 35 W
Impedance: 6 Ω
Frequency Range: 90 Hz to 20 kHz
Dimensions (W × H × D): 143 mm × 67 mm × 106 mm
Mass: 420 g
Designs & specifications are subject to change without notice.
