JVC TH-D337H User Manual

18
GB
AUX / Optical / HDMI Operation
There are OPTICAL / AUX 1 / AUX 2 and HDMI ARC sockets located at the rear of the unit.
1. Before connecting to the mains socket, ensure all the connections are completed.
2. While in the On mode, press SOURCE on the unit repeatedly to select between AUX 1,
AUX 2, OPTICAL, and HDMI ARC mode.
Alternatively,
t press AUX 1/ AUX 2 on the remote control to select AUX 1 and AUX 2 mode.
t press OPTICAL on the remote control to select OPTICAL mode.
t press HDMI ARC on the remote control to select HDMI ARC mode.
3. Operate your audio device directly for playback features.
While in OPTICAL/HDMI ARC mode, if there’s no sound output from the unit, ensure that the audio
setting of the input source (e.g. TV, game console, DVD player, etc.) is set to PCM (Refer to the user
manual of the input source device for its audio setting details) with OPTICAL/ HDMI input.
TH-D337H_IB_170505_will.indd 18 5/5/2017 4:19 PM

JVC TH-D337H Specifications

Power

power supply	AC120V~ 60Hz
power consumption	30 W
output power	30 W x 2

Connectivity

bluetooth version	V 4.2
maximum power transmitted	<20 dbm
frequency bands	2402 MHz ~ 2480 MHz

Audio Input

usb socket	5V == 0.5A
audio input sensitivity	700mV
frequency response	120Hz - 20KHz

Remote Control

distance	6m
angle	30°
battery type	CR2025

Weight and Dimensions

unit dimension	952 x 63 x 65.7 mm
