JVC TH-D337H User Manual

10
GB
Wall Mounting
t Installation must be carried out by qualied personnel only. Incorrect assembly can result in severe
personal injury and property damage (if you intend to install this product yourself, you must check
for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the
installer’s responsibility to verify that the wall will safely support the total load of the soundbar.
t Additional tools (not included) are required for the installation.
t Do not overtighten screws.
t Keep this instruction manual for future reference.
t Use an electronic stud nder to check the wall type before drilling and mounting.
1. Remove the screws from the main unit.
764 mm
Wall (Front view)
3. Drill 2 parallel holes (Ø 3-8 mm each according to wall type) in the wall. The distance
between the holes should be 764 mm.
2. Attach the wall brackets to the main unit with the screws removed from the main unit.
TH-D337H_IB_170505_will.indd 10 5/5/2017 4:19 PM

JVC TH-D337H Specifications

Power

power supply	AC120V~ 60Hz
power consumption	30 W
output power	30 W x 2

Connectivity

bluetooth version	V 4.2
maximum power transmitted	<20 dbm
frequency bands	2402 MHz ~ 2480 MHz

Audio Input

usb socket	5V == 0.5A
audio input sensitivity	700mV
frequency response	120Hz - 20KHz

Remote Control

distance	6m
angle	30°
battery type	CR2025

Weight and Dimensions

unit dimension	952 x 63 x 65.7 mm
