JVC TH-D337H User Manual

11
GB
5. Insert 1 screw (included) into each dowel. Be sure to leave a 5 mm gap between the
wall and the screw’s head. Lift the unit over the heads of the screws and slot into place.
4. Firmly x 1 dowel (included) into each hole in the wall if necessary.
Dowel
Solid wall (i.e., Solid brick,
Solid concrete, Solid wood,
Solid wooden battens)
Drywall, Plaster wall,
Lath wall, etc.
5 mm
25-30 mm
TH-D337H_IB_170505_will.indd 11 5/5/2017 4:19 PM

JVC TH-D337H Specifications

Power

power supply	AC120V~ 60Hz
power consumption	30 W
output power	30 W x 2

Connectivity

bluetooth version	V 4.2
maximum power transmitted	<20 dbm
frequency bands	2402 MHz ~ 2480 MHz

Audio Input

usb socket	5V == 0.5A
audio input sensitivity	700mV
frequency response	120Hz - 20KHz

Remote Control

distance	6m
angle	30°
battery type	CR2025

Weight and Dimensions

unit dimension	952 x 63 x 65.7 mm
