1-2 (No.MB393)
SPECIFICATION
Center unit (XV-THS33/XV-THS11)
Front speakers (SP-THS33F)
Center speaker (SP-THS33C)
Surround speakers (SP-THS33S)
Audio section Front/Center/Surround 33 W per channel, RMS at 6 Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer 40 W, RMS at 4 Ω at 100 Hz, with 10% total harmonic distortion.
Video section Video System PAL
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB (Composite signal when "RGB" is selected)
Video output level Composite:1.0 V(p-p)/75 Ω
S-video-Y:1.0 V(p-p)/75 Ω
S-video-C:0.3 V(p-p)/75 Ω
RGB:0.7 V(p-p)/75 Ω
Tuner section Tuning Range FM:87.50 MHz to 108.00 MHz
AM:522 kHz to 1 629 kHz
General Power Requirements AC 230 V , 50 Hz
Power Consumption 100 W (at operation)
1.3 W (in standby mode)
Dimensions (W × H × D) 360 mm × 65 mm × 370 mm
Mass 5.3 kg
Type 1-Way Bass-Reflex Type (Magnetically-shielded Type)
Speaker 5.5 cm cone × 1
Power Handling Capacity 35 W
Impedance 6 Ω
Frequency Range 90 Hz to 20 000 Hz
Sound Pressure Level 75 dB/W·m
Dimensions (W × H × D) 230 mm × 1 102 mm × 260 mm
Mass 3.2 kg each
Dimensions (W × H × D) 129 mm × 284 mm × 337 mm
Mass 3.0 kg
Type 1-Way Bass-Reflex Type (Magnetically-shielded Type)
Speaker 5.5 cm cone × 2
Power Handling Capacity 35 W
Impedance 6 Ω
Frequency Range 95 Hz to 20 000 Hz
Sound Pressure Level 81 dB/W·m
Dimensions (W × H × D) 220 mm × 84 mm × 88.5 mm
Mass 0.97 kg
Type 1-Way Bass-Reflex Type
Speaker 5.5 cm cone × 1
Power Handling Capacity 35 W
Impedance 6 Ω
Frequency Range 105 Hz to 20 000 Hz
Sound Pressure Level 75 dB/W·m
Dimensions (W × H × D) 83 mm × 131 mm × 93.5 mm
Mass 0.50 kg each
