Front board
Block No. [0][2][0][0]
Audio board
Block No. [0][3][0][0]
R6502 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6504 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6505 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6506 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6507 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6508 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6509 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6510 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6511 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6512 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6513 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6514 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6515 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6516 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6517 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6518 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R6601 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6602 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6603 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6604 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6605 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R6606 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6607 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6608 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6609 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R6610 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6611 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R6612 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6613 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6614 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6615 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6616 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6617 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6618 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
 L901 QQR1105-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L952 QQL44BK-220Z COIL 22uH K
L955 QQL26AK-220Z COIL 22uH K
L957 QQL244K-100Z COIL 10uH K
L959 QQL244K-100Z COIL 10uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0097-001 SW TRANSF
CN401 QGF1036C1-15 CONNECTOR FFC/FPC (1-15)
CN402 QGF1036C1-17 CONNECTOR FFC/FPC (1-17)
CN403 QGF1036C1-09 CONNECTOR FFC/FPC (1-9)
CN404 QGD2504C1-05Z CONNECTOR (1-5)
CN405 QGD2504C1-05Z CONNECTOR (1-5)
CN406 QGD2504C1-04Z CONNECTOR (1-4)
CN407 QGD2504C1-05Z CONNECTOR (1-5)
CN408 QGF1036C1-05 CONNECTOR FFC/FPC (1-5)
CN409 QGF1036C1-08 CONNECTOR FFC/FPC (1-8)
CN410 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1036C1-29 CONNECTOR FFC/FPC (1-29)
CN412 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN451 QGF1036C1-13 CONNECTOR FFC/FPC (1-13)
CN452 QGF1036C1-13 CONNECTOR FFC/FPC (1-13)
 CP471 ICP-N5-T IC PROTECTOR 250mA
 CP951 ICP-N10-T IC PROTECTOR 400mA
 CP952 ICP-N5-T IC PROTECTOR 250mA
EP401 QNZ0136-001Z EARTH PLATE
EP402 QNZ0136-001Z EARTH PLATE
EP403 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW901 QUM219-06DGZ4 PARA RIBON WIR
FW902 QUM21A-06DGZ4 PARA RIBON WIR
HS901 E70306-014 HEAT SINK
J4402 QNN0572-001 PIN JACK
J4403 QNZ0625-001 RGB CONNECTOR
J4891 QNS0089-001 3.5 JACK
K4702 QQR0621-001Z COIL
 P901 QNC0091-001 AC INLET
X4071 QAX0263-001Z CRYSTAL 4.332MHz
 Symbol No. Part No. Part Name Description Local
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC501 MN101C35DKW IC(MPU)
IC511 GP1UM271XK IR DETECT UNIT 38kHz
Q501 KRC102S-X DIGI TRANSISTOR
Q502 KRC102S-X DIGI TRANSISTOR
Q551 KRC102M-T DIGI TRANSISTOR
Q552 KRC111M-T TRANSISTOR
D551 SLR343BBT/H-L/T LED
C501 NCB31HK-471X C CAPACITOR 470pF 50V K
C502 NCB31HK-471X C CAPACITOR 470pF 50V K
C503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C504 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C505 NBE21AM-226X TA E CAPACITOR 22uF 10V M
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB21CK-105X C CAPACITOR 1uF 16V K
R501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R504 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R552 NRSA63J-121X MG RESISTOR 120 Ω 1/16W J
R553 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
BK501 LV43659-001A FL HOLDER
BK502 LV43659-001A FL HOLDER
CN501 QGF1036F1-13 CONNECTOR FFC/FPC (1-13)
DI501 QLF0131-002 FL TUBE
X501 NAX0623-001X C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC151 CD4066BM-X IC
IC152 CD4066BM-X IC
IC153 BD3814FV-X IC
IC158 RC4580ID-X IC
IC159 RC4580ID-X IC
IC160 RC4580ID-X IC
IC509 GP1FA352RZ OPT RECEIVER
IC531 RC4580ID-X IC
IC581 RC4580ID-X IC
IC591 RC4580ID-X IC
Q511 KRC102S-X DIGI TRANSISTOR
Q1131 IMX9-W TRANSISTOR
Q1133 IMX9-W TRANSISTOR
Q1135 IMX9-W TRANSISTOR
Q1137 2SC3661-X TRANSISTOR
Q1251 KRA104S-X DIGI TRANSISTOR
Q1252 KRA104S-X DIGI TRANSISTOR
D511 SLR-343VC-T LED
C541 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1001 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1002 QETN1EM-107Z E CAPACITOR 100uF 25V M
C1003 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Symbol No. Part No. Part Name Description Local
