3-21
SD board
Block No. [0][4][0][0]
Mother board
Block No. [0][5][0][0]
R1170 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1171 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J S7
R1171 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J S8,S9
R1172 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J S7
R1172 NRSA63J-512X MG RESISTOR 5.1k Ω 1/16W J S8,S9
R1173 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1174 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1175 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J S7
R1175 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J S8,S9
R1176 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1197 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1201 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1202 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1251 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1252 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1253 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1254 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2525 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2526 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2531 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2532 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2533 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R2534 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2537 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2538 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2539 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2540 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2551 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2552 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2553 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2554 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2560 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2561 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2562 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2563 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2565 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2566 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2567 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2568 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2584 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2585 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R2586 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R2587 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2588 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2599 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6002 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R6003 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R6004 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6006 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
CN441 QGF1036C1-29 CONNECTOR FFC/FPC (1-29)
CN442 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN511 QGF1036F1-13 CONNECTOR FFC/FPC (1-13)
EP101 E409182-001SM GRAND TERMINAL
J1101 QNN0215-001 SURROUND JACK
J1103 QND0118-001 DIN CONNECTOR
J6001 QNS0231-001 JACK
JS541 QSW1059-001 JOG VOLUME
K1101 NQR0007-002X FERRITE BEADS
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
S521 QSW0683-001Z PUSH SW
S522 QSW0683-001Z PUSH SW
S523 QSW0683-001Z PUSH SW
S526 QSW0683-001Z PUSH SW
S527 QSW0683-001Z PUSH SW
S528 QSW0683-001Z PUSH SW
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
C801 NCB31CK-104X C CAPACITOR 0.1uF 16V K S7,S9
C802 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M S7,S9
C803 NCB31HK-103X C CAPACITOR 0.01uF 50V K S7,S9
C805 NCB31HK-102X C CAPACITOR 1000pF 50V K S7,S9
R801 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J S7,S9
R804 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J S7,S9
R805 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J S7,S9
R806 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J S7,S9
R807 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J S7,S9
R808 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J S7,S9
R809 NRS181J-0R0X MG RESISTOR 0 Ω 1/8W J S7,S9
R810 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J S7,S9
R811 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J S7,S9
R812 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J S7,S9
R813 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J S7,S9
CN801 QNZ0683-001 SD CARD CONNECT S7,S9
CN802 QGF0523F1-16W CONNECTOR FFC/FPC (1-16) S7,S9
K801 NQR0022-002X FERRITE BEADS S7,S9
K802 NQR0022-002X FERRITE BEADS S7,S9
K803 NQR0022-002X FERRITE BEADS S7,S9
K804 NQR0022-002X FERRITE BEADS S7,S9
K805 NQR0022-002X FERRITE BEADS S7,S9
K806 NQR0022-002X FERRITE BEADS S7,S9
K807 NQR0022-002X FERRITE BEADS S7,S9
K808 NQR0022-002X FERRITE BEADS S7,S9
K809 NQR0022-002X FERRITE BEADS S7,S9
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-400 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
IC602 S-80840CNNB-W IC
Q151 KTD863/Y/-T TRANSISTOR
Q152 KTC3203/OY/-T TRANSISTOR
Q501 UN2113-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q503 KTC3875/YG/-X SI TRANSISTOR
Q504 KTA1504/YG/-X SI TRANSISTOR
Q505 UN2211-X TRANSISTOR
Q517 UN2213-X DIGI TRANSISTOR
Q523 KTC3875/YG/-X SI TRANSISTOR
Q524 KTA1504/YG/-X SI TRANSISTOR
Q525 KTC3875/YG/-X SI TRANSISTOR
Q542 KTC3875/YG/-X SI TRANSISTOR
Q603 KTC3875/YG/-X SI TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 KTA1504/YG/-X SI TRANSISTOR
Q2201 KTA1504/YG/-X SI TRANSISTOR
Q2301 KTA1504/YG/-X SI TRANSISTOR
Q2401 KTA1504/YG/-X SI TRANSISTOR
Q2501 KTA1504/YG/-X SI TRANSISTOR
Q2601 KTA1504/YG/-X SI TRANSISTOR
Q2701 KTC3875/YG/-X SI TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 UN2211-X TRANSISTOR
Q3101 KTC3875/YG/-X SI TRANSISTOR
Q3102 KTC3875/YG/-X SI TRANSISTOR
Q3201 KTC3875/YG/-X SI TRANSISTOR
Q3202 KTC3875/YG/-X SI TRANSISTOR
Q3301 KTC3875/YG/-X SI TRANSISTOR
